Description Specifications Series Pricing CAD Documents

Description

General part information

EVALSTGAP2 Series

The EVALSTGAP2HSCM is an isolated single gate driver.

The gate driver is characterized by 4 A current capability and rail-to-rail outputs, making the device suitable also for high power inverter applications such as motor drivers in industrial applications equipped with MOSFET / IGBT power switch.

The configuration featuring single output pin and Miller CLAMP function allows avoiding gate spikes during fast commutations in half-bridge topologies.

Technical Specifications

Parameters and characteristics for this part

Specification	EVALSTGAP2DM

Contents	Board
Embedded	No
Function	Gate Driver
Supplied Contents	Board(s)
Type	Power Management
Utilized IC / Part	STGAP2DM

EVALSTGAP2 Series

Demonstration board for STGAP2HSCM isolated 4 A single gate driver

Part	Supplied Contents	Type	Primary Attributes	Contents	Function	Utilized IC / Part	Embedded
STMicroelectronics EVALSTGAP2HSCM	Board(s)	Power Management	Isolated	Board	Gate Driver	STGAP2HSCM
STMicroelectronics EVALSTGAP2HSM	Board(s)	Power Management	Isolated	Board	Gate Driver	STGAP2HSM
STMicroelectronics EVALSTGAP2DM	Board(s)	Power Management		Board	Gate Driver	STGAP2DM	No
