10129381-906004BLF
ActiveAmphenol ICC (FCI)
CONN HEADER VERT 6POS 2.54MM
Deep-Dive with AI
Search across all available documentation for this part.
10129381-906004BLF
ActiveAmphenol ICC (FCI)
CONN HEADER VERT 6POS 2.54MM
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 10129381-906004BLF |
|---|---|
| Applications | Industrial, Medical, General Purpose, Telecommunications |
| Connector Type | Cuttable, Header |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 1 µin |
| Contact Finish Thickness - Mating | 0.025 µm |
| Contact Length - Mating [x] | 0.318 " |
| Contact Length - Mating [x] | 8.08 mm |
| Contact Length - Post | 0.09 " |
| Contact Length - Post | 2.29 mm |
| Contact Material | Copper Alloy |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating (Amps) | 3 A |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Insulation Height | 0.1 in |
| Insulation Height | 2.54 mm |
| Insulation Material | Thermoplastic |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 6 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -55 °C |
| Overall Contact Length | 12.9 mm |
| Overall Contact Length | 0.508 in |
| Pitch - Mating | 0.1 in |
| Pitch - Mating | 2.54 mm |
| Row Spacing - Mating [x] | 2.54 mm |
| Row Spacing - Mating [x] | 0.1 in |
| Shrouding | Unshrouded |
| Style | Board to Board, Cable |
| Termination | Solder |
10129381 Series
| Part | Connector Type | Current Rating (Amps) | Number of Positions Loaded | Insulation Color | Applications | Contact Length - Post [x] | Contact Length - Post [x] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Type | Insulation Material | Shrouding | Overall Contact Length | Overall Contact Length | Style | Number of Rows | Mounting Type | Contact Material | Pitch - Mating | Pitch - Mating | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Fastening Type | Contact Finish - Mating | Material Flammability Rating | Operating Temperature [Max] | Operating Temperature [Min] | Insulation Height | Insulation Height | Termination | Contact Length - Mating [x] | Contact Length - Mating | Contact Shape | Number of Positions | Number of Positions | Contact Length - Post | Contact Length - Post | Contact Length - Mating [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 0.12 in | 3.05 mm | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.45 " | 11.43 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.23 in | 5.84 mm | Square | 8 | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.508 in | 12.9 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 16 | 0.09 " | 2.29 mm | 8.08 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.42 " | 10.67 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.23 in | 5.84 mm | Square | 16 | 0.09 " | 2.29 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.508 in | 12.9 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 0.09 " | 2.29 mm | 8.08 mm | |||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.508 in | 12.9 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 24 | 0.09 " | 2.29 mm | 8.08 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.508 in | 12.9 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 6 | 0.09 " | 2.29 mm | 8.08 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.42 " | 10.67 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.23 in | 5.84 mm | Square | 30 | 0.09 " | 2.29 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 0.12 in | 3.05 mm | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.538 " | 13.67 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 4 | 8.08 mm | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 0.12 in | 3.05 mm | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.45 " | 11.43 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.23 in | 5.84 mm | Square | 10 | ||||
Amphenol ICC (FCI) | Cuttable Header | 3 A | All | Black | General Purpose Industrial Medical Telecommunications | 0.12 in | 3.05 mm | 1 µin | 0.025 µm | Male Pin | Thermoplastic | Unshrouded | 0.538 " | 13.67 mm | Board to Board Cable | 2 | Through Hole | Copper Alloy | 0.1 in | 2.54 mm | 2.54 mm | 0.1 in | Push-Pull | Gold | UL94 V-0 | 105 ░C | -55 °C | 0.1 in | 2.54 mm | Solder | 0.318 " | Square | 50 | 8.08 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 0.19 | |
| 10 | $ 0.14 | |||
| 100 | $ 0.11 | |||
| 500 | $ 0.09 | |||
| 1000 | $ 0.07 | |||
| 5000 | $ 0.07 | |||
| 10000 | $ 0.07 | |||
Description
General part information
10129381 Series
Connector Header Through Hole 6 position 0.100" (2.54mm)
