BQ24161EVM-721
ActiveEVAL MODULE FOR BQ24161-721
Deep-Dive with AI
Search across all available documentation for this part.
BQ24161EVM-721
ActiveEVAL MODULE FOR BQ24161-721
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24161EVM-721 | BQ24161 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion/Polymer |
| Battery Pack Voltage | - | 3.7 V |
| Charge Current - Max | - | 2.5 A |
| Current - Charging | - | Constant - Programmable |
| Embedded | False | False |
| Fault Protection | - | Over Voltage, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Interface | - | I2C |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 24-VFQFN Exposed Pad, DSBGA, 49-UFBGA |
| Primary Attributes | Li-Ion (1 Cell) | Li-Ion (1 Cell) |
| Secondary Attributes | I2C Interface(s) | I2C Interface(s) |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 24-VQFN (4x4), 49-DSBGA (2.8x2.8) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24161 | BQ24161 |
| Voltage - Supply (Max) | - | 10 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 178.80 | |
BQ24161 Series
I2C 1cell 2.5A Buck battery charger with dual-input, Power Path and PSEL
| Part | Mounting Type | Battery Pack Voltage | Supplier Device Package | Current - Charging | Package / Case | Number of Cells | Interface | Fault Protection | Battery Chemistry | Charge Current - Max [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Supply (Max) [Max] | Type | Function | Utilized IC / Part | Supplied Contents | Primary Attributes | Secondary Attributes | Embedded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24161RGER | Surface Mount | 3.7 V | 24-VQFN (4x4) | Constant - Programmable | 24-VFQFN Exposed Pad | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161BRGET | Surface Mount | 3.7 V | 24-VQFN (4x4) | Constant - Programmable | 24-VFQFN Exposed Pad | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161YFFT | Surface Mount | 3.7 V | 49-DSBGA (2.8x2.8) | Constant - Programmable | 49-UFBGA, DSBGA | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161BRGER | Surface Mount | 3.7 V | 24-VQFN (4x4) | Constant - Programmable | 24-VFQFN Exposed Pad | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161BYFFR | Surface Mount | 3.7 V | 49-DSBGA (2.8x2.8) | Constant - Programmable | 49-UFBGA, DSBGA | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161YFFR | Surface Mount | 3.7 V | 49-DSBGA (2.8x2.8) | Constant - Programmable | 49-UFBGA, DSBGA | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161BYFFT | Surface Mount | 3.7 V | 49-DSBGA (2.8x2.8) | Constant - Programmable | 49-UFBGA, DSBGA | 1 | I2C | Over Temperature, Over Voltage | Lithium Ion/Polymer | 2.5 A | 85 °C | -40 °C | 10 V | |||||||
Texas Instruments BQ24161EVM-721 | Power Management | Battery Charger | BQ24161 | Board(s) | Li-Ion (1 Cell) | I2C Interface(s) |
Description
General part information
BQ24161 Series
The BQ24160, BQ24160A, BQ24161, BQ24161B, BQ24163, and BQ24168 are highly integrated single-cell Li-ion battery charger and system power path management devices targeted for space-limited, portable applications with high-capacity batteries. The single-cell charger has dual inputs which allow operation from either a USB port or a higher-power input supply (that is, AC adapter or wireless charging input) for a versatile solution. The two inputs are fully isolated from each other and are easily selectable using the I2C interface.
The power path management feature allows the BQ2416xx to power the system from a high-efficiency DC-DC converter while simultaneously and independently charging the battery. The power path management architecture enables the system to run with a defective or absent battery pack and enables instant system turnon even with a totally discharged battery or no battery.
The BQ24160, BQ24160A, BQ24161, BQ24161B, BQ24163, and BQ24168 are highly integrated single-cell Li-ion battery charger and system power path management devices targeted for space-limited, portable applications with high-capacity batteries. The single-cell charger has dual inputs which allow operation from either a USB port or a higher-power input supply (that is, AC adapter or wireless charging input) for a versatile solution. The two inputs are fully isolated from each other and are easily selectable using the I2C interface.
