AHDPBS-18-002

Active

Amphenol Sine Systems Corp

CONN BACKSH SZ18 BLK 1 7/16-12

Search across all available documentation for this part.

Active

Amphenol Sine Systems Corp

CONN BACKSH SZ18 BLK 1 7/16-12

Technical Specifications

Parameters and characteristics for this part

Specification	AHDPBS-18-002

Cable Exit	180 °
Color	Black
Diameter - Outside [diameter]	1.551 in
Diameter - Outside [diameter]	39.4 mm
Features	Strain Relief
For Use With/Related Products	AHDP Series Connector with WTA Modification
Includes	1 Backshell, 1 Compression Nut
Ingress Protection	IP67 - Dust Tight, Waterproof
Material	Thermoplastic
Shell Size - Insert	18
Shielding	Unshielded
Thread Size	1 7/16-12 UN
Type	Backshell

Part	Diameter - Outside [diameter]	Diameter - Outside [diameter]	Color	Shielding	Features	Type	For Use With/Related Products	Ingress Protection	Cable Exit	Includes	Thread Size	Shell Size - Insert	Material	Cable Opening [Max] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Min] [diameter]	Cable Opening [Max] [diameter]	Primary Material	Cable Opening [custom]	Cable Opening [custom]
Amphenol Sine Systems Corp AHDPBS-18-002	1.551 in	39.4 mm	Black	Unshielded	Strain Relief	Backshell	AHDP Series Connector with WTA Modification	IP67 - Dust Tight Waterproof	180 °	1 Backshell 1 Compression Nut	1 7/16-12 UN	18	Thermoplastic
Amphenol Sine Systems Corp AHDPBS-18-SM01	1.535 in	39 mm	Black	Unshielded		Backshell	AHDP Series		180 °	1 Backshell 1 Cage Clamp 1 Compression Nut 1 Rubber Ring	1 7/16-12 UN-2B	18	Thermoplastic	16 mm	12 mm	0.472 in	0.63 in
Amphenol Sine Systems Corp AHDPBS-16L017-1805	1.614 "	41 mm	Black	Unshielded	Snap-On	Backshell	AHDP Series Connector with WTA Modification	IP68 - Dust Tight Waterproof	180 °			18	Thermoplastic					Plastic	28.9 mm	1.138 in
Amphenol Sine Systems Corp AHDPBS-24L015-005	1.512 in	38.4 mm	Black	Unshielded	Strain Relief	Backshell	AHDP Series Connector with WTA Modification		180 °		M35x1.75	24	Thermoplastic					Plastic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Black Connector Backshell 1 7/16-12 UN 18
