3UG45112AN20

Active

Siemens

MONITORING RELAY,ANALOG,260V,60H

Search across all available documentation for this part.

Active

Siemens

MONITORING RELAY,ANALOG,260V,60H

Technical Specifications

Parameters and characteristics for this part

Part	Type	Operating Temperature [Min]	Operating Temperature [Max]	Trip Range [Max]	Trip Range [Min]	Voltage - Supply [Max]	Voltage - Supply [Min]	Circuit	Contact Rating @ Voltage	Mounting Type
Siemens 3UG45112BP20	Phase Sequence	-25 °C	60 °C	500 A AC	320 V AC	500 VAC	320 VAC	DPDT (2 Form C)	3 A 400 VAC	DIN Rail
Siemens 3UG45112AN20	Phase Sequence	-25 °C	60 °C	260 V AC	160 V AC	260 VAC	160 VAC		3 A 400 VAC	DIN Rail
Siemens 3UG45112BQ20	Phase Sequence	-25 °C	60 °C	690 V AC	420 V AC	690 VAC	420 VAC	DPDT (2 Form C)	3 A 400 VAC	DIN Rail
Siemens 3UG45112AQ20	Phase Sequence	-25 °C	60 °C	690 V AC	420 V AC	690 VAC	420 VAC		3 A 400 VAC	DIN Rail
Siemens 3UG45111BQ20	Phase Sequence	-25 °C	60 °C	690 V AC	420 V AC	690 VAC	420 VAC	DPDT (2 Form C)	3 A 400 VAC	DIN Rail
Siemens 3UG45112BN20	Phase Sequence	-25 °C	60 °C	260 V AC	160 V AC	260 VAC	160 VAC	DPDT (2 Form C)	3 A 400 VAC	DIN Rail

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 150.00

General part information

Phase Sequence 160 ~ 260VAC

Technical documentation and resources
