IMM101T046MXUMA1
ActiveInfineon Technologies
IMOTION™ SMART IPM WITH MOSFET POWER STAGE AND PMSM/BLDC MOTOR CONTROLLER IN 12X12 MM PQFN PACKAGE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
IMM101T046MXUMA1
ActiveInfineon Technologies
IMOTION™ SMART IPM WITH MOSFET POWER STAGE AND PMSM/BLDC MOTOR CONTROLLER IN 12X12 MM PQFN PACKAGE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | IMM101T046MXUMA1 |
|---|---|
| Applications | General Purpose |
| Current - Output | 4 A |
| Function | Driver |
| Interface | PWM |
| Motor Type - AC, DC | Brushless DC (BLDC) |
| Motor Type - Stepper | Bipolar |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 115 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Half Bridge (3) |
| Package / Case | 38-PowerVQFN |
| Supplier Device Package | PG-IQFN-38-1 |
| Technology | Power MOSFET |
| Voltage - Supply [Max] | 16.5 V |
| Voltage - Supply [Min] | 13.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 9.66 | |
| 10 | $ 8.72 | |||
| 25 | $ 8.32 | |||
| 100 | $ 7.22 | |||
| 250 | $ 6.90 | |||
| 500 | $ 6.29 | |||
| 1000 | $ 5.48 | |||
| Digi-Reel® | 1 | $ 9.66 | ||
| 10 | $ 8.72 | |||
| 25 | $ 8.32 | |||
| 100 | $ 7.22 | |||
| 250 | $ 6.90 | |||
| 500 | $ 6.29 | |||
| 1000 | $ 5.48 | |||
| Tape & Reel (TR) | 2000 | $ 5.02 | ||
Description
General part information
IMM101 Series
iMOTION™ IPMintegrating MCE 2.0 motor controller and three phase inverter with 600 V / 1.26 Ω RDS(on)MOSFETs in 12x12 mm PQFN package.
