AM12TW-4805SZ

Active

aimtec

DC DC CONVERTER 5.1V 12W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM12TW-4805SZ

Active

aimtec

DC DC CONVERTER 5.1V 12W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AM12TW-4805SZ	AM12T Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	UL, CE	CE, UL
Current - Output (Max) [Max]	2.4 A	2.4 - 3.5 A
Efficiency	89 %	87 - 89 %
Features	Remote On/Off	Remote On/Off
Mounting Type	Through Hole	Through Hole
Number of Outputs	1	1
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	24-DIP Module	24-DIP Module, 8 Leads, 24-DIP Module, 23-DIP Module
Package / Case	-	8 Leads
Power (Watts)	12 W	12 W
Size / Dimension	-	10.2 mm
Size / Dimension	-	20.3 mm
Size / Dimension [x]	1.25 "	1.25 "
Size / Dimension [x]	31.8 mm	31.8 mm
Size / Dimension [y]	0.8 in	0.8 in
Size / Dimension [y]	20.3 mm	20.3 mm
Size / Dimension [z]	10.7 mm	10.7 mm
Size / Dimension [z]	0.42 in	0.4 - 0.42 in
Supplier Device Package	-	24-DIP
Type	Isolated Module	Isolated Module
Voltage - Input (Max) [Max]	75 V	18 - 75 V
Voltage - Input (Min) [Min]	18 V	9 - 36 V
Voltage - Isolation	1.6 kV	1.6 kV
Voltage - Output 1	5.1 V	3.3 - 5.1 V

AM12T Series

DC DC CONVERTER 5.1V 12W

Part	Approval Agency	Mounting Type	Voltage - Output 1	Number of Outputs	Voltage - Input (Min) [Min]	Package / Case	Current - Output (Max) [Max]	Voltage - Input (Max) [Max]	Power (Watts)	Type	Efficiency	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Applications	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Features	Size / Dimension [z]	Size / Dimension [y]	Supplier Device Package	Package / Case
aimtec AM12TW-2405SZ	CE	Through Hole	5.1 V	1	9 V	24-DIP Module, 8 Leads	2.4 A	36 V	12 W	Isolated Module	89 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)	10.7 mm	1.25 "	0.8 in	20.3 mm	31.8 mm	0.42 in
aimtec AM12TW-2403SZ	CE, UL	Through Hole	3.3 V	1	9 V	24-DIP Module	3.5 A	36 V	12 W	Isolated Module	87 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)	10.7 mm	1.25 "	0.8 in	20.3 mm	31.8 mm	0.42 in	Remote On/Off
aimtec AM12T-1203SZ	CE	Through Hole	3.3 V	1	9 V	24-DIP Module	3.5 A	18 V	12 W	Isolated Module	87 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)		1.25 "	0.8 in		31.8 mm	0.4 "	Remote On/Off	10.2 mm	20.3 mm
aimtec AM12T-4805SZ	CE	Through Hole	5 V	1	36 V	24-DIP Module	2.4 A	75 V	12 W	Isolated Module	89 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)		1.25 "	0.8 in		31.8 mm	0.4 "	Remote On/Off	10.2 mm	20.3 mm
aimtec AM12T-1205SZ	CE	Through Hole	5 V	1	9 V	23-DIP Module	2.4 A	18 V	12 W	Isolated Module	89 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)		1.25 "	0.8 in		31.8 mm	0.4 "	Remote On/Off	10.2 mm	20.3 mm	24-DIP	8 Leads
aimtec AM12TW-4805SZ	CE, UL	Through Hole	5.1 V	1	18 V	24-DIP Module	2.4 A	75 V	12 W	Isolated Module	89 %	85 °C	-40 °C	1.6 kV	ITE (Commercial)	10.7 mm	1.25 "	0.8 in	20.3 mm	31.8 mm	0.42 in	Remote On/Off

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1	$ 31.12
		5	$ 29.34
		10	$ 28.60
		25	$ 27.66
		50	$ 26.97
		100	$ 26.29
		250	$ 25.42

Description

General part information

AM12T Series

Isolated Module DC DC Converter 1 Output 5.1V 2.4A 18V - 75V Input

Documents

Technical documentation and resources
