37306-3101-0W0 FL
Active3M (TC)
CONN RCPT 6POS IDC 24-26AWG GOLD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
37306-3101-0W0 FL
Active3M (TC)
CONN RCPT 6POS IDC 24-26AWG GOLD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 37306-3101-0W0 FL |
|---|---|
| Cable Termination | IDC |
| Color | Black |
| Connector Type | Receptacle |
| Contact Finish | Gold |
| Contact Finish Thickness | 8 çin |
| Contact Finish Thickness | 0.203 çm |
| Contact Type | Female Socket |
| Features | Closed End |
| Mounting Type | Free Hanging (In-Line) |
| Number of Positions | 6 |
| Number of Rows | 2 |
| Pitch [x] | 0.079 in |
| Pitch [x] | 2 mm |
| Row Spacing | 6.5 mm |
| Row Spacing | 0.256 in |
| Wire Gauge [Max] | 26 AWG |
| Wire Gauge [Min] | 24 AWG |
| Wire Type | Discrete |
37306 Series
| Part | Wire Gauge [Min] | Wire Gauge [Max] | Color | Number of Positions | Contact Type | Cable Termination | Contact Finish Thickness | Contact Finish Thickness | Wire Type | Number of Rows | Pitch [x] | Pitch [x] | Row Spacing | Row Spacing | Connector Type | Contact Finish | Features | Mounting Type | Fastening Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
3M (TC) | 20 AWG | 22 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | 6.5 mm | 0.256 in | Receptacle | Gold | Closed End | Free Hanging (In-Line) | |
3M (TC) | 20 AWG | 22 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | 6.5 mm | 0.256 in | Receptacle | Gold | Closed End | Free Hanging (In-Line) | |
3M (TC) | 24 AWG | 26 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | 6.5 mm | 0.256 in | Receptacle | Gold | Closed End | Free Hanging (In-Line) | |
3M (TC) | 24 AWG | 26 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | Socket | Gold | Closed End | Panel Mount Snap-In | Latch Holder | ||
3M (TC) | 24 AWG | 26 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | Socket | Gold | Closed End | Panel Mount Snap-In | Latch Holder | ||
3M (TC) | 20 AWG | 22 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | Socket | Gold | Closed End | Panel Mount Snap-In | Latch Holder | ||
3M (TC) | 24 AWG | 26 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | Socket | Gold | Closed End | Panel Mount Snap-In | Latch Holder | ||
3M (TC) | 20 AWG | 22 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | 6.5 mm | 0.256 in | Receptacle | Gold | Closed End | Free Hanging (In-Line) | |
3M (TC) | 20 AWG | 22 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | Socket | Gold | Closed End | Panel Mount Snap-In | Latch Holder | ||
3M (TC) | 24 AWG | 26 AWG | Black | 6 | Female Socket | IDC | 8 çin | 0.203 çm | Discrete | 2 | 0.079 in | 2 mm | 6.5 mm | 0.256 in | Receptacle | Gold | Closed End | Free Hanging (In-Line) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 100 | $ 4.54 | |
Description
General part information
37306 Series
6 Position Rectangular Receptacle Connector IDC Gold 24-26 AWG
