BQ24735EVM-710
ActiveEVAL MODULE FOR BQ24735-710
Deep-Dive with AI
Search across all available documentation for this part.
BQ24735EVM-710
ActiveEVAL MODULE FOR BQ24735-710
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24735EVM-710 | BQ24735 Series |
|---|---|---|
| Battery Chemistry | - | Multi-Chemistry |
| Battery Pack Voltage | - | 16.8 V |
| Contents | Board(s) | Board(s) |
| Embedded | False | False |
| Fault Protection | - | Over Current, Over Voltage, Short Circuit |
| Function | Battery Monitor | Battery Monitor |
| Interface | - | I2C |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 4 |
| Number of Cells | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 20-VFQFN Exposed Pad |
| Primary Attributes | 4 A | 4 A |
| Primary Attributes [Max] | 4 Cells | 4 Cells |
| Primary Attributes [Min] | 1 Cells | 1 Cells |
| Supplied Contents | Board(s) | Board(s) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24735 | BQ24735 |
| Voltage - Supply (Max) | - | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 58.80 | |
BQ24735 Series
SMBus 1-4 cell Buck battery charge controller to support turbo boost mode
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Battery Chemistry | Mounting Type | Voltage - Supply (Max) [Max] | Fault Protection | Number of Cells [Max] [custom] | Number of Cells [Min] [custom] | Package / Case | Interface | Battery Pack Voltage | Utilized IC / Part | Contents | Type | Primary Attributes [Max] | Primary Attributes | Primary Attributes [Min] | Function | Embedded | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24735RGRT | 85 °C | -40 °C | Multi-Chemistry | Surface Mount | 24 V | Over Current, Over Voltage, Short Circuit | 4 | 1 | 20-VFQFN Exposed Pad | I2C | 16.8 V | |||||||||
Texas Instruments BQ24735EVM-710 | BQ24735 | Board(s) | Power Management | 4 Cells | 4 A | 1 Cells | Battery Monitor | Board(s) | ||||||||||||
Texas Instruments BQ24735RGRR | 85 °C | -40 °C | Multi-Chemistry | Surface Mount | 24 V | Over Current, Over Voltage, Short Circuit | 4 | 1 | 20-VFQFN Exposed Pad | I2C | 16.8 V |
Description
General part information
BQ24735 Series
The bq24735 device is a high-efficiency, synchronous battery charger, offering low component count for space-constrained, multichemistry battery charging applications. The bq24735 device supports turbo boost by allowing battery discharge energy to the system when system power demand is temporarily higher than the adapter maximum power level so the adapter will not crash.
The bq24735 device uses two charge pumps to separately drive N-channel MOSFETs (ACFET, RBFET, and BATFET) for automatic system power source selection.
SMBus controlled input current, charge current, and charge voltage digital-to-analog converters (DACs) allow for very high-regulation accuracies that can be easily programmed by the system power management microcontroller.
