SEAF8-40-1-S-10-2-RA-GP

Active

Samtec Inc.

CONN HD ARRAY RCPT 400P R/A SMD

Search across all available documentation for this part.

Active

Samtec Inc.

CONN HD ARRAY RCPT 400P R/A SMD

Technical Specifications

Parameters and characteristics for this part

Part	Number of Positions	Features	Contact Finish Thickness	Contact Finish Thickness	Pitch [x]	Pitch [x]	Mounting Type	Mated Stacking Heights	Contact Finish	Height Above Board	Height Above Board	Connector Type	Number of Rows
Samtec Inc. SEAF8-40-05.0-L-04-2-K	160	Board Guide Pick and Place	10 Áin	0.25 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female
Samtec Inc. SEAF8-40-05.0-S-04-2-K	160	Board Guide Pick and Place	30 Áin	0.76 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female
Samtec Inc. SEAF8-40-1-S-10-2-RA-GP	400	Board Guide Mating Flange	30 Áin	0.76 Ám	0.8 mm	0.031 in	Surface Mount Right Angle		Gold			High Density Array Female	10
Samtec Inc. SEAF8-40-05.0-S-04-3	160	Board Guide	30 Áin	0.76 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female
Samtec Inc. SEAF8-40-05.0-L-10-3	400	Board Guide	10 Áin	0.25 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female	10
Samtec Inc. SEAF8-40-05.0-S-08-2-K	320	Board Guide Pick and Place	30 Áin	0.76 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female	8
Samtec Inc. SEAF8-40-05.0-S-06-3	240	Board Guide	30 Áin	0.76 Ám	0.8 mm	0.031 in	Surface Mount	7 mm 10 mm	Gold	4.57 mm	0.18 in	High Density Array Female	6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	75	$ 43.73

General part information

400 Position Connector High Density Array, Female Surface Mount, Right Angle Gold
