JWL4048S3V3

Active

XP POWER

DC DC CONVERTER 3.3V 40W

Search across all available documentation for this part.

Active

XP POWER

DC DC CONVERTER 3.3V 40W

Technical Specifications

Parameters and characteristics for this part

Part	Operating Temperature [Min]	Operating Temperature [Max]	Current - Output (Max) [Max]	Voltage - Isolation	Number of Outputs	Package / Case	Power (Watts)	Voltage - Input (Max) [Max]	Voltage - Input (Min) [Min]	Voltage - Output 1	Applications	Efficiency	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Mounting Type	Type	Features	Standard Number	Control Features	Voltage - Output 2
XP POWER JWL4048S3V3	-40 °C	105 ░C	8 A	1.5 kV	1	6-DIP Module	40 W	75 V	18 V	3.3 V	ITE (Commercial)	89 %	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	Through Hole	Isolated Module	Remote On/Off SCP	62368-1	Active High Enable
XP POWER JWL4048D15	-40 °C	105 ░C	1.33 A	1.5 kV	2	6-DIP Module	40 W	75 V	18 V	15 V	ITE (Commercial)	88 %	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	Through Hole	Isolated Module	Remote On/Off SCP	62368-1	Active High Enable	-15 V
XP POWER JWL4048S05	-40 °C	105 ░C	8 A	1.5 kV	1	6-DIP Module	40 W	75 V	18 V	5 V	ITE (Commercial)	90 %	25.4 mm	0.4 "	2 in	10.2 mm	50.8 mm	25.4 mm	Through Hole	Isolated Module	Remote On/Off SCP	62368-1	Active High Enable

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 3.3V 8A 18V - 75V Input
