DRV8316CTQRGFRQ1
ActiveTexas Instruments
AUTOMOTIVE 40-V MAX 8-A PEAK THREE-PHASE MOTOR DRIVER WITH INTEGRATED CURRENT SENSING
Deep-Dive with AI
Search across all available documentation for this part.
DRV8316CTQRGFRQ1
ActiveTexas Instruments
AUTOMOTIVE 40-V MAX 8-A PEAK THREE-PHASE MOTOR DRIVER WITH INTEGRATED CURRENT SENSING
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DRV8316CTQRGFRQ1 | DRV8316C-Q1 Series |
|---|---|---|
| Current - Output | 8 A | 8 A |
| Function | Driver - Fully Integrated, Control and Power Stage | Driver - Fully Integrated, Control and Power Stage |
| Grade | Automotive | Automotive |
| Interface | PWM | PWM, SPI |
| Motor Type - AC, DC | Brushless DC (BLDC) | Brushless DC (BLDC) |
| Motor Type - Stepper | Multiphase | Multiphase |
| Mounting Type | Surface Mount | Surface Mount |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Output Configuration | Half Bridge (3) | Half Bridge (3) |
| Package / Case | 40-VFQFN Exposed Pad | 40-VFQFN Exposed Pad |
| Supplier Device Package | 40-VQFN | 40-VQFN |
| Technology | NMOS | NMOS |
| Voltage - Load [Max] | 35 V | 35 V |
| Voltage - Load [Min] | 4.5 V | 4.5 V |
| Voltage - Supply [Max] | 35 V | 35 V |
| Voltage - Supply [Min] | 4.5 V | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 5.35 | |
| 10 | $ 4.81 | |||
| 25 | $ 4.54 | |||
| 100 | $ 3.94 | |||
| 250 | $ 3.74 | |||
| 500 | $ 3.35 | |||
| 1000 | $ 2.83 | |||
| Digi-Reel® | 1 | $ 5.35 | ||
| 10 | $ 4.81 | |||
| 25 | $ 4.54 | |||
| 100 | $ 3.94 | |||
| 250 | $ 3.74 | |||
| 500 | $ 3.35 | |||
| 1000 | $ 2.83 | |||
| Tape & Reel (TR) | 3000 | $ 2.31 | ||
| Texas Instruments | LARGE T&R | 1 | $ 3.74 | |
| 100 | $ 3.27 | |||
| 250 | $ 2.30 | |||
| 1000 | $ 1.85 | |||
DRV8316C-Q1 Series
Automotive 40-V max 8-A peak three-phase motor driver with integrated current sensing
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Function | Supplier Device Package | Motor Type - Stepper | Current - Output | Technology | Grade | Voltage - Load [Max] | Voltage - Load [Min] | Motor Type - AC, DC | Interface | Package / Case | Output Configuration | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments DRV8316CTQRGFRQ1 | 4.5 V | 35 V | Driver - Fully Integrated, Control and Power Stage | 40-VQFN | Multiphase | 8 A | NMOS | Automotive | 35 V | 4.5 V | Brushless DC (BLDC) | PWM | 40-VFQFN Exposed Pad | Half Bridge (3) | Surface Mount | -40 °C | 125 °C |
Texas Instruments DRV8316CRQRGFRQ1 | 4.5 V | 35 V | Driver - Fully Integrated, Control and Power Stage | 40-VQFN | Multiphase | 8 A | NMOS | Automotive | 35 V | 4.5 V | Brushless DC (BLDC) | PWM, SPI | 40-VFQFN Exposed Pad | Half Bridge (3) | Surface Mount | -40 °C | 125 °C |
