BQ24105EVM
ActiveTexas Instruments
EVALUATION MODULE FOR BQ24105
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
BQ24105EVM
ActiveTexas Instruments
EVALUATION MODULE FOR BQ24105
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24105EVM | BQ24105 Series |
|---|---|---|
| Battery Chemistry | - | Multi-Chemistry, Lithium Ion/Polymer |
| Battery Pack Voltage | - | 12.6 - 15.5 V |
| Charge Current - Max | - | 2 A |
| Contents | Board(s) | Board(s) |
| Current - Charging | - | Constant - Programmable |
| Fault Protection | - | Over Voltage, Over Temperature |
| Function | Battery Charger | Battery Charger |
| Grade | - | Automotive |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Number of Cells | - | 3 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 20-VFQFN Exposed Pad |
| Programmable Features | - | Current, Timer |
| Qualification | - | AEC-Q100 |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 20-VQFN (3.5x4.5) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24105 | BQ24105 |
| Voltage - Supply (Max) | - | 16 V |
