Description

General part information

1553 Series

Breadboard, Prepunched Insulating Non-Plated Through Hole (NPTH) 2 Hole Pad (Single Side) 0.100" (2.54mm)

Technical Specifications

Parameters and characteristics for this part

Specification	1553DBPCB

Circuit Pattern	Hole Pad (Single Side)
Circuit Pattern Hole Count	2
Hole Diameter	0.042 in
Material	Acrylonitrile Butadiene Styrene (ABS)
Pitch	0.1 in
Plating	Non-Plated Through Hole (NPTH)
Proto Board Type	Breadboard, Prepunched Insulating
Size / Dimension Length	4.18 in
Size / Dimension Width	72.39 mm

1553 Series

Part	Features	Area (L x W)	Color	Thickness	Material	Container Type	Design	Height	Size / Dimension Length	Size / Dimension Width	Material Flammability Rating	Proto Board Type	Plating	Circuit Pattern	Circuit Pattern Hole Count	Hole Diameter	Pitch
Hammond Manufacturing 1553TTBKBAT	9V and AA Battery Compartment Flame Retardant PCB Supports	20.4 in²	Black	0.09 in	ABS	Box	End Panel(s) Hand Held Split Sides	1.1 in	6.496 in	3.15 in	UL94 V-0
Hammond Manufacturing 1553AAGY	PCB Supports	5.81 in²	Gray	0.079 in	ABS	Box	Hand Held Split Sides	0.669 in	2.953 in	1.972 in	UL94 HB
Hammond Manufacturing 1553DRDBKBAT	9V and AA Battery Compartment PCB Supports	20.3 in²	Red	0.108 in	ABS	Box	Hand Held Split Sides	0.984 in	5.797 in	3.504 in	UL94 HB
Hammond Manufacturing 1553CGY	PCB Supports	14.4 in²	Gray	0.098 in	ABS	Box	Hand Held Split Sides	1.26 in	4.615 in	3.109 in	UL94 HB
Hammond Manufacturing 1553DBPCB					Acrylonitrile Butadiene Styrene (ABS)				4.18 in	72.39 mm		Breadboard Prepunched Insulating	Non-Plated Through Hole (NPTH)	Hole Pad (Single Side)	2	0.042 in	0.1 in
Hammond Manufacturing 1553BYLBK	PCB Supports	14.4 in²	Yellow	0.108 in	ABS	Box	Hand Held Split Sides	0.945 in	4.615 in	3.109 in	UL94 HB
Hammond Manufacturing 1553DGY	PCB Supports	20.3 in²	Gray	0.108 in	ABS	Box	Hand Held Split Sides	0.984 in	5.797 in	3.504 in	UL94 HB
Hammond Manufacturing 1553DRDBK	PCB Supports	20.3 in²	Red	0.108 in	ABS	Box	Hand Held Split Sides	0.984 in	5.797 in	3.504 in	UL94 HB
Hammond Manufacturing 1553DBK	PCB Supports	20.3 in²	Black	0.108 in	ABS	Box	Hand Held Split Sides	0.984 in	5.797 in	3.504 in	UL94 HB
Hammond Manufacturing 1553CGYBAT	9V and AA Battery Compartment PCB Supports	14.4 in²	Gray	0.098 in	ABS	Box	Hand Held Split Sides	1.26 in	4.615 in	3.109 in	UL94 HB
