TPS65835RKPT
ActiveADVANCED POWER MANAGEMENT IC (PMIC) WITH INTEGRATED MSP430 FOR ACTIVE SHUTTER 3D GLASSES
Deep-Dive with AI
Search across all available documentation for this part.
TPS65835RKPT
ActiveADVANCED POWER MANAGEMENT IC (PMIC) WITH INTEGRATED MSP430 FOR ACTIVE SHUTTER 3D GLASSES
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 5.12 | |
| 10 | $ 4.60 | |||
| 25 | $ 4.35 | |||
| 100 | $ 3.77 | |||
| Digi-Reel® | 1 | $ 5.12 | ||
| 10 | $ 4.60 | |||
| 25 | $ 4.35 | |||
| 100 | $ 3.77 | |||
| Tape & Reel (TR) | 250 | $ 2.39 | ||
| Texas Instruments | SMALL T&R | 1 | $ 3.87 | |
| 100 | $ 3.39 | |||
| 250 | $ 2.38 | |||
| 1000 | $ 1.91 | |||
Description
General part information
TPS65835 Series
The TPS65835 is a power management unit (PMU) for active shutter 3D glasses consisting of a power management core and an MSP430 microcontroller. The power management core has an integrated power path, linear charger, LDO, boost converter, and full H-bridge analog switches for left and right shutter operation in a pair of active shutter 3D glasses. The MSP430 core supports the synchronization and communications from an IR, RF, or other communications module through the integrated universal serial communications and timer interfaces for operation of the H-bridge switches on the power management core.
The TPS65835 is a power management unit (PMU) for active shutter 3D glasses consisting of a power management core and an MSP430 microcontroller. The power management core has an integrated power path, linear charger, LDO, boost converter, and full H-bridge analog switches for left and right shutter operation in a pair of active shutter 3D glasses. The MSP430 core supports the synchronization and communications from an IR, RF, or other communications module through the integrated universal serial communications and timer interfaces for operation of the H-bridge switches on the power management core.
