DAC7311EVM
ActiveTexas Instruments
EVAL MODULE FOR DAC7311
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet

DAC7311EVM
ActiveTexas Instruments
EVAL MODULE FOR DAC7311
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
Specification | DAC7311EVM | DAC7311 Series |
---|---|---|
Architecture | - | String DAC |
DAC Type | Voltage | Voltage |
Data Interface | QSPI™, MICROWIRE™, Serial, SPI™ | SPI, DSP, QSPI™, MICROWIRE™, Serial, SPI™ |
Differential Output | - | False |
INL/DNL (LSB) | - | -1.4 Ohm |
INL/DNL (LSB) | - | 1.4 Ohm |
Mounting Type | - | Surface Mount |
Number of Bits | 12 | 12 |
Number of DAC's | 1 | 1 |
Operating Temperature | - | 125 °C |
Operating Temperature | - | -40 °C |
Output Type | - | Voltage - Buffered |
Package / Case | - | 6-TSSOP, SC-88, SOT-363 |
Reference Type | - | Supply |
Settling Time | 12 µs | 12 µs |
Supplied Contents | Board(s) | Board(s) |
Supplier Device Package | - | SC-70-6 |
Utilized IC / Part | DAC7311 | DAC7311 |
Voltage - Supply, Analog | - | 2 V |
Voltage - Supply, Analog | - | 5.5 V |
Voltage - Supply, Digital | - | 2 V |
Voltage - Supply, Digital | - | 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Distributor | Package | Quantity | $ | |
---|---|---|---|---|
Digikey | Box | 1 | $ 58.80 |
DAC7311 Series
12-BIT, SINGLE-CHANNEL, ULTRA-LOW POWER DAC IN 6-PIN SC70 PACKAGE FOR BATTERY POWERED APPLICATIONS 6-SC70 -40 TO 125
Part | Package / Case | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog [Max] | Mounting Type | Reference Type | Supplier Device Package | Architecture | Data Interface | Number of Bits | Output Type | INL/DNL (LSB) [Min] | INL/DNL (LSB) [Max] | Voltage - Supply, Digital [Min] | Voltage - Supply, Digital [Max] | Settling Time | Operating Temperature [Max] | Operating Temperature [Min] | Differential Output | Number of DAC's | Utilized IC / Part | Supplied Contents | DAC Type |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments DAC7311IDCKTG4 | 6-TSSOP, SC-88, SOT-363 | 2 V | 5.5 V | Surface Mount | Supply | SC-70-6 | String DAC | DSP, SPI | 12 | Voltage - Buffered | -1.4 Ohm | 1.4 Ohm | 2 V | 5.5 V | 12 µs | 125 °C | -40 °C | |||||
Texas Instruments DAC7311IDCKT | 6-TSSOP, SC-88, SOT-363 | 2 V | 5.5 V | Surface Mount | Supply | SC-70-6 | String DAC | DSP, SPI | 12 | Voltage - Buffered | -1.4 Ohm | 1.4 Ohm | 2 V | 5.5 V | 12 µs | 125 °C | -40 °C | |||||
Texas Instruments DAC7311EVM | MICROWIRE™, QSPI™, Serial, SPI™ | 12 | 12 µs | 1 | DAC7311 | Board(s) | Voltage | |||||||||||||||
Texas Instruments DAC7311IDCKR | 6-TSSOP, SC-88, SOT-363 | 2 V | 5.5 V | Surface Mount | Supply | SC-70-6 | String DAC | DSP, SPI | 12 | Voltage - Buffered | -1.4 Ohm | 1.4 Ohm | 2 V | 5.5 V | 12 µs | 125 °C | -40 °C |
Description
General part information
DAC7311 Series
DAC7311 12 Bit Samples Per Second Digital to Analog Converter (DAC) Evaluation Board
