BTE-100-02-F-D-A

Active

Samtec Inc.

CONN HDR 200POS SMD GOLD

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

BTE-100-02-F-D-A

Active

Samtec Inc.

CONN HDR 200POS SMD GOLD

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	BTE-100-02-F-D-A

Connector Type	Header, Outer Shroud Contacts
Contact Finish	Gold
Contact Finish Thickness	3 Áin
Contact Finish Thickness	0.076 Ám
Features	Board Guide
Height Above Board	7.06 mm
Height Above Board	0.278 "
Mated Stacking Heights [z]	8.03 mm
Mounting Type	Surface Mount
Number of Rows	2
Pitch [x]	0.8 mm
Pitch [x]	0.031 in

BTE-100 Series

Part	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Number of Rows	Features	Mounting Type	Contact Finish	Pitch [x]	Pitch [x]	Mated Stacking Heights [z]	Height Above Board	Height Above Board	Mated Stacking Heights	Height Above Board [z]	Height Above Board [z]
Samtec Inc. BTE-100-02-F-D-A	3 Áin	0.076 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in	8.03 mm	7.06 mm	0.278 "
Samtec Inc. BTE-100-03-F-D-A-K	3 Áin	0.076 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in				11.03 mm	0.396 in	10.06 mm
Samtec Inc. BTE-100-01-H-D-A	30 Áin	0.76 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in		4.06 mm	0.16 in	5.03 mm
Samtec Inc. BTE-100-05-L-D-A	10 Áin	0.25 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in				19.1 mm	0.719 in	18.26 mm
Samtec Inc. BTE-100-01-F-D-EM2	3 Áin	0.076 Ám	Header Outer Shroud Contacts	2		Board Edge Straddle Mount	Gold	0.8 mm	0.031 in
Samtec Inc. BTE-100-01-F-D-A	3 Áin	0.076 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in		4.06 mm	0.16 in	5.03 mm
Samtec Inc. BTE-100-04-L-D-A	10 Áin	0.25 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in		15.27 mm	0.601 in	16.1 mm
Samtec Inc. BTE-100-05-F-D-A	3 Áin	0.076 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in				19.1 mm	0.719 in	18.26 mm
Samtec Inc. BTE-100-01-L-D-A	10 Áin	0.25 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in		4.06 mm	0.16 in	5.03 mm
Samtec Inc. BTE-100-07-L-D-A	10 Áin	0.25 Ám	Header Outer Shroud Contacts	2	Board Guide	Surface Mount	Gold	0.8 mm	0.031 in		24.23 mm	0.954 in	25 mm
