RN218-2.2-02-3M3
ActiveTE Connectivity Raychem Cable Protection
CMC 3.3MH 2.2A 2LN TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | RN218-2.2-02-3M3 |
|---|---|
| Approval Agency | ENEC, UR, VDE |
| Current Rating (Max) [Max] | 2.2 A |
| DC Resistance (DCR) (Max) | 100 mOhm |
| Filter Type | Power Line |
| Height (Max) [Max] | 0.799 " |
| Height (Max) [Max] | 20.3 mm |
| Inductance @ Frequency | 3.3 mH |
| Mounting Type | Through Hole |
| Number of Lines | 2 |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 Lead |
| Package / Case | Vertical |
| Size / Dimension [x] | 18 mm |
| Size / Dimension [x] | 0.709 in |
| Size / Dimension [y] | 0.492 " |
| Size / Dimension [y] | 12.5 mm |
| Voltage Rating - AC | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 2.34 | |
| 10 | $ 1.82 | |||
| 25 | $ 1.64 | |||
| 50 | $ 1.52 | |||
| 100 | $ 1.41 | |||
| 250 | $ 1.27 | |||
| 500 | $ 1.21 | |||
Description
General part information
RN218 Series
3.3 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 2.2A DCR 100mOhm (Typ)
