MC68HC16Z1CAG16

Freescale Semiconductor - NXP

IC MCU 16BIT ROMLESS 144LQFP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

MC68HC16Z1CAG16

Freescale Semiconductor - NXP

IC MCU 16BIT ROMLESS 144LQFP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	MC68HC16Z1CAG16

Connectivity	SPI, SCI, EBI/EMI
Core Processor	CPU16
Core Size	16-Bit
Data Converters [custom]	8
Data Converters [custom]	10
Mounting Type	Surface Mount
Number of I/O	16
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Oscillator Type	Internal
Package / Case	144-LQFP
Peripherals	POR, PWM, WDT
Program Memory Type	ROMless
RAM Size	1 K
Speed	16 MHz
Supplier Device Package	144-LQFP (20x20)
Voltage - Supply (Vcc/Vdd) [Max]	5.5 V
Voltage - Supply (Vcc/Vdd) [Min]	2.7 V

MC68HC16 Series

Part	Oscillator Type	Data Converters [custom]	Data Converters [custom]	Connectivity	Peripherals	Core Size	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Package / Case	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Voltage - Supply (Vcc/Vdd) [Min]	Voltage - Supply (Vcc/Vdd) [Max]	Program Memory Type	RAM Size	Speed	Number of I/O	Core Processor	Program Memory Size	RAM Size
Freescale Semiconductor - NXP MC68HC16Z1MEH16	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit	24.13	24.13	132-PQFP	132-BQFP Bumpered	-40 °C	125 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	16 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1CPV16	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	16 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1CAG25	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	25 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z3BCPV25	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	Mask ROM		16 MHz	16	HC16	4 KB	4K x 8
Freescale Semiconductor - NXP MC68HC16Z1CAG20	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	20 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1MAG16	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	125 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	16 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1VEH16	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit	24.13	24.13	132-PQFP	132-BQFP Bumpered	-40 °C	105 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	16 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1CPV25	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	25 MHz	16	CPU16
Freescale Semiconductor - NXP MC68HC16Z1CAG16	Internal	8	10	EBI/EMI SCI SPI	POR PWM WDT	16-Bit			144-LQFP (20x20)	144-LQFP	-40 °C	85 °C	Surface Mount	2.7 V	5.5 V	ROMless	1 K	16 MHz	16	CPU16

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	300	$ 28.45

Description

General part information

MC68HC16 Series

CPU16 HC16 Microcontroller IC 16-Bit 16MHz ROMless 144-LQFP (20x20)
