General part information
8 (4 Pair) Conductor Multi-Pair, Cat5e Cable Orange 24 AWG 1000.0' (304.8m)
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1212 003U1000 | 1212 Series |
|---|---|---|
| - | - | |
| Cable Type | Multi-Pair, Cat5e | Multi-Pair, Cat5e |
| Conductor Insulation | Polyolefin (PO) | Polyolefin (PO) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand | Solid | Solid |
| Features | Rip Cord | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.206 " | 0.206 " |
| Jacket (Insulation) Diameter [diameter] | 5.23 mm | 5.23 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Orange | Green, Blue, Yellow, Orange, Gray, Black |
| Length | 1000 ft | 1000 - 2500 ft |
| Length | 304.8 m | 304.8 - 762 m |
| Number of Conductors | 8 | 8 |
| Operating Temperature [Max] | 75 ░C | 75 ░C |
| Operating Temperature [Min] | -25 °C | -25 °C |
| Ratings | UL Style CMR | UL Style CMR |
| Usage | Network | Network |
| Voltage | 300 V | 300 V |
| Wire Gauge | 24 AWG | 24 AWG |
CAT5E+ 4PR U/UTP CMR BOX
| Part | Length | Length | Conductor Material | Conductor Strand | Conductor Insulation | Ratings | Cable Type | Jacket Color | Usage | Features | Voltage | Number of Conductors | Jacket (Insulation) Material | Wire Gauge | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 1212 005U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Green | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 006U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Blue | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 0062500 | 2500 ft | 762 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Blue | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 004U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Yellow | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 003U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Orange | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 0092500 | ||||||||||||||||||
Belden Inc. 1212 008U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Gray | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
Belden Inc. 1212 010U1000 | 1000 ft | 304.8 m | Copper, Bare | Solid | Polyolefin (PO) | UL Style CMR | Multi-Pair, Cat5e | Black | Network | Rip Cord | 300 V | 8 | Poly-Vinyl Chloride (PVC), Riser | 24 AWG | 0.206 " | 5.23 mm | -25 °C | 75 ░C |
