TMCM-1180-CABLE
ActiveAnalog Devices Inc./Maxim Integrated
CABLE LOOM FOR TMCM-1181
Deep-Dive with AI
Search across all available documentation for this part.
TMCM-1180-CABLE
ActiveAnalog Devices Inc./Maxim Integrated
CABLE LOOM FOR TMCM-1181
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | TMCM-1180-CABLE | TMCM-1180 Series |
|---|---|---|
| Accessory Type | Cable Assembly | Cable Assembly |
| Control / Drive Type | - | Bipolar, Stepper |
| Current - Output | - | 5.5 A |
| For Use With/Related Products | TMCM-1181 Series | TMCM-1181 Series |
| Interface | - | RS-485, RS-232, Step / Direction, USB, CAN |
| Motor Type | - | Stepper |
| Mounting Type | - | Chassis Mount |
| Operating Temperature | - | 50 °C |
| Operating Temperature | - | -20 C |
| Type | - | Board |
| Usage | Motor | Motor |
| Voltage - Load | - | 18 V |
| Voltage - Load | - | 55 V |
| Voltage - Supply | - | 48 V |
| Voltage - Supply | - | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 19.79 | |
| 1 | $ 19.73 | |||
TMCM-1180 Series
STEPPER DRIVER 5.5A 18-55V LOAD
| Part | Voltage - Load [Min] | Voltage - Load [Max] | Control / Drive Type | Voltage - Supply [Max] | Voltage - Supply [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Type | Mounting Type | Motor Type | Current - Output | Usage | For Use With/Related Products | Accessory Type | Interface |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated TMCM-1180-TMCL | 18 V | 55 V | Bipolar, Stepper | 48 V | 24 V | 50 °C | -20 C | Board | Chassis Mount | Stepper | 5.5 A | ||||
Analog Devices Inc./Maxim Integrated TMCM-1180-CABLE | Motor | TMCM-1181 Series | Cable Assembly | ||||||||||||
Analog Devices Inc./Maxim Integrated TMCM-1180-CANOPEN | 18 V | 55 V | Bipolar, Stepper | 48 V | 24 V | 50 °C | -20 C | Board | Chassis Mount | Stepper | 5.5 A | CAN, RS-232, RS-485, Step / Direction, USB |
Description
General part information
TMCM-1180 Series
Cable Assembly
Documents
Technical documentation and resources
No documents available
