VK204-25

Active

Matrix Orbital

VFD ALPHA/NUM DISPL 20X4 SER

Search across all available documentation for this part.

Active

Matrix Orbital

VFD ALPHA/NUM DISPL 20X4 SER

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 174.74

General part information

Vacuum Fluorescent Display (VFD) 20 x 4 Character Serial 98.00mm x 60.00mm x 27.70mm

Technical documentation and resources

Parameters and characteristics commom to parts in this series

VFD ALPHA/NUM DISPLAY 20X4

Part	Display Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Display Format [y]	Display Format [x]	Operating Temperature [Min]	Operating Temperature [Max]	Character Size [y]	Character Size [z]	Interface	Format [x]	Format [y]	Outline L x W x H [x]	Outline L x W x H [y]	Outline L x W x H [z]	Viewing Area [y]	Viewing Area [x]	Number of Dots [custom]	Number of Dots [custom]
Matrix Orbital VK204-25-VPT	Character	9 V	35 V	4	20	-20 C	70 °C	2.4 mm	4.7 mm	Serial	5 Dots	7	98 mm	60 mm	27.7 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-USB-E	Character	4.75 V	5.25 V	4	20	-40 °C	85 °C	2.4 mm	4.7 mm	USB	5 Dots	7	98 mm	60 mm	30.5 mm	20.9 mm	70.8 mm	100	28
Matrix Orbital VK204-25-422-E	Character	4.75 V	5.25 V	4	20	-40 °C	85 °C	2.4 mm	4.7 mm		5 Dots	7	98 mm	60 mm	30.5 mm	20.9 mm	70.8 mm	100	28
Matrix Orbital VK204-25-USB	Character	4.75 V	5.25 V	4	20	-20 C	70 °C	2.4 mm	4.7 mm	USB	5 Dots	7	98 mm	60 mm	30.5 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-422-VPT	Character	9 V	35 V	4	20	-20 C	70 °C	4.7 mm	2.4 mm				98 mm	60 mm	28.98 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-VPT-E	Character	9 V	15 V	2	20	-40 °C	85 °C	4.7 mm	2.4 mm	I2C			98 mm	60 mm	28.98 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25	Character			4	20	-20 C	70 °C	2.4 mm	4.7 mm	Serial	5 Dots	7	98 mm	60 mm	27.7 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-E	Character	9 V	15 V	4	20	-40 °C	85 °C	2.4 mm	4.7 mm	Serial	5 Dots	7	98 mm	60 mm	27.7 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-422	Character	4.75 V	5.25 V	4	20	-20 C	70 °C	2.4 mm	4.7 mm		5 Dots	7	98 mm	60 mm	30.5 mm	20.9 mm	70.8 mm
Matrix Orbital VK204-25-422-VPT-E	Character	9 V	35 V	4	20	-20 C	70 °C	4.7 mm	2.4 mm				98 mm	60 mm	28.98 mm	20.9 mm	70.8 mm
