AA60S2400A

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 24V 2.5A 60W 4-PIN

Search across all available documentation for this part.

Obsolete

Delta Electronics

AC/DC POWER SUPPLY SINGLE-OUT 24V 2.5A 60W 4-PIN

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AA60S2400A	AA60S Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	UL, CE	CE, UL
Current - Output (Max) [Max]	2.5 A	1.67 - 4 A
Current - Output 1	-	4 - 10 A
Efficiency	84 %	79 - 84 %
Features	Universal Input	Universal Input, DC Input Capable
Line Regulation	±0.2%	±0.2%
Load Regulation	0.5 %	0.5 %
Minimum Load Required	-	False
Mounting Type	Through Hole	Chassis Mount, Through Hole
Number of Outputs	1	1
Operating Temperature	-	-10 °C
Operating Temperature	-	158 °F
Operating Temperature [Max]	70 °C	70 °C
Operating Temperature [Min]	-10 °C	-10 °C
Package / Case	6-DIP Module, 4 Leads	6-DIP Module, 4 Leads
Power (Watts)	60 W	60 W
Size / Dimension [x]	88.9 mm	88.9 - 112 mm
Size / Dimension [x]	3.5 in	3.5 - 4.41 "
Size / Dimension [y]	2.66 "	2.66 - 2.67 in
Size / Dimension [y]	67.5 mm	67.5 - 67.8 mm
Size / Dimension [z]	34.2 mm	34.2 - 38 mm
Size / Dimension [z]	1.35 "	1.35 - 1.5 "
Standard Number	60950-1	60950-1
Type	Enclosed	Enclosed
Voltage - Isolation	-	3000 V
Voltage - Output 1	24 V	5 - 36 V
Weight	0.761 lb	0.761 lb
Weight	345.18 g	345.18 g

AC/DC CONVERTER 15V 60W

Part	Operating Temperature [Min] [custom]	Operating Temperature [Max] [custom]	Type	Efficiency	Mounting Type	Features	Voltage - Isolation	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Applications	Current - Output 1	Voltage - Output 1	Approval Agency	Number of Outputs	Current - Output (Max) [Max]	Package / Case	Standard Number	Line Regulation	Power (Watts)	Weight	Weight	Operating Temperature [Min]	Operating Temperature [Max]	Load Regulation
Delta Electronics AA60S1500C	-10 °C	158 °F	Enclosed	83 %	Chassis Mount	DC Input Capable, Universal Input	3000 V	38 mm	112 mm	67.8 mm	1.5 "	2.67 in	4.41 "	ITE (Commercial)	4 A	15 V	CE	1
Delta Electronics AA60S1500A			Enclosed	83 %	Through Hole	Universal Input		34.2 mm	88.9 mm	67.5 mm	1.35 "	2.66 "	3.5 in	ITE (Commercial)		15 V	CE, UL	1	4 A	6-DIP Module, 4 Leads	60950-1	±0.2%	60 W	0.761 lb	345.18 g	-10 °C	70 °C	0.5 %
Delta Electronics AA60S2400A			Enclosed	84 %	Through Hole	Universal Input		34.2 mm	88.9 mm	67.5 mm	1.35 "	2.66 "	3.5 in	ITE (Commercial)		24 V	CE, UL	1	2.5 A	6-DIP Module, 4 Leads	60950-1	±0.2%	60 W	0.761 lb	345.18 g	-10 °C	70 °C	0.5 %
Delta Electronics AA60S0500C	-10 °C	158 °F	Enclosed	79 %	Chassis Mount	DC Input Capable, Universal Input	3000 V	38 mm	112 mm	67.8 mm	1.5 "	2.67 in	4.41 "	ITE (Commercial)	10 A	5 V	CE	1
Delta Electronics AA60S3600A			Enclosed	84 %	Through Hole	Universal Input		34.2 mm	88.9 mm	67.5 mm	1.35 "	2.66 "	3.5 in	ITE (Commercial)		36 V	CE, UL	1	1.67 A	6-DIP Module, 4 Leads	60950-1	±0.2%	60 W	0.761 lb	345.18 g	-10 °C	70 °C	0.5 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Enclosed AC DC Converters 1 Output 24V 2.5A 85 ~ 264 VAC Input
