PA-120N-13P
ObsoleteMEAN WELL USA Inc.
BATT CHRGR OPEN FRAME 13.8V 7.2A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PA-120N-13P |
|---|---|
| Approval Agency | cULus, CB, GS, CE |
| Battery Cell Size | 12 V |
| Battery Chemistry | Lead Acid |
| Charge Current - Max [Max] | 7.2 A |
| Features | LED Indicator |
| Mounting Type | Chassis Mount |
| Number of Cells | 1 |
| Operating Temperature [Max] | 45 °C |
| Operating Temperature [Min] | -10 °C |
| Power - Max [Max] | 99.36 W |
| Size / Dimension [x] | 5.67 in |
| Size / Dimension [x] | 144 mm |
| Size / Dimension [y] | 90 mm |
| Size / Dimension [y] | 3.54 in |
| Size / Dimension [z] | 33 mm |
| Size / Dimension [z] | 1.3 " |
| Termination Style | Rectangular Connector |
| Type | Open Frame |
| Voltage - Input [Max] | 132 VAC, 264 VAC |
| Voltage - Input [Min] | 88 VAC, 176 VAC |
| Voltage - Nominal | 13.8 V |
| Weight | 1100 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
PA-120 Series
Open Frame Battery Charger 13.8V 7.2A 12V
