112TW1-1E

Active

Honeywell Sensing and Productivity Solutions

SWITCH TOGGLE DPDT 5A 125V

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet Micro-Toggle Switch, Line Guide

112TW1-1E

Active

Honeywell Sensing and Productivity Solutions

SWITCH TOGGLE DPDT 5A 125V

Deep-Dive with AI

DocumentsDatasheet Micro-Toggle Switch, Line Guide

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 280.61

Description

General part information

112TW1 Series

Toggle Switch DPDT Panel Mount

Documents

Technical documentation and resources

Datasheet

Micro-Toggle Switch, Line Guide

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	112TW1-1E	112TW1 Series

Actuator Length [x]	29.46 mm	17.27 - 29.46 mm
Actuator Type	Locking Lever	Standard Round, Locking Lever
Bushing Thread	15/32-32	15/32-32
Circuit	DPDT	DPDT, SP3T
Current Rating (Amps)	5 A	5 A
Features	-	Jumper needed to achieve triple throw
Illumination	Non-Illuminated	Non-Illuminated
Ingress Protection	Environment Sealed	Environment Sealed
Operating Temperature [Max]	71 °C	71 °C
Operating Temperature [Min]	-65 ░C	-65 ░C
Panel Cutout Dimensions [diameter]	12.4 mm	12.4 mm
Switch Function	On-Off-On	Mom-Off-Mom, On-Mom, On-On, On-On-On, On-Off-On, On-On-Mom
Termination Style	IWTS	IWTS
Voltage Rating - AC	125 V	125 V
Voltage Rating - DC	28 V	28 V

112TW1 Series

SWITCH TOGGLE DPDT 5A 125V

Part	Switch Function	Current Rating (Amps)	Actuator Length [x]	Circuit	Ingress Protection	Voltage Rating - DC	Termination Style	Illumination	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Type	Voltage Rating - AC	Bushing Thread	Panel Cutout Dimensions [diameter]	Features
Honeywell Sensing and Productivity Solutions 112TW1-7	Mom-Off-Mom	5 A	17.27 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Standard Round	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-8F	On-Mom	5 A	29.46 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Locking Lever	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-51	On-Mom	5 A	17.27 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Standard Round	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-3G	On-On	5 A	29.46 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Locking Lever	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-10A	On-On-On	5 A	29.46 mm	SP3T	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Locking Lever	125 V	15/32-32	12.4 mm	Jumper needed to achieve triple throw
Honeywell Sensing and Productivity Solutions 112TW1-1E	On-Off-On	5 A	29.46 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Locking Lever	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-3	On-On	5 A	17.27 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Standard Round	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-3D	On-On	5 A	29.46 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Locking Lever	125 V	15/32-32	12.4 mm
Honeywell Sensing and Productivity Solutions 112TW1-50	On-On-Mom	5 A	17.27 mm	DPDT	Environment Sealed	28 V	IWTS	Non-Illuminated	71 °C	-65 ░C	Standard Round	125 V	15/32-32	12.4 mm
