Specification	R123464110

Body Finish	Gold
Body Material	Brass
Center Contact Material	Beryllium Copper
Center Contact Plating	Gold
Connector Style	QMA
Connector Type	Jack, Female Socket
Contact Termination	Solder
Dielectric Material	Polytetrafluoroethylene (PTFE)
Fastening Type	Snap-On
Features	Extended Insulation
Frequency - Max	6000 MHz
Housing Color	Gold
Impedance	50 Ohm
Mating Cycles	100 cycles
Mounting Feature	Flange
Mounting Type	Panel Mount, Through Hole
Number of Ports	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Shield Termination	Solder
Voltage Rating	500 V

R12346 Series

Part	Frequency - Max	Features	Center Contact Material	Mounting Feature	Shield Termination	Fastening Type	Mounting Type	Housing Color	Connector Style	Number of Ports	Connector Type	Impedance	Contact Termination	Body Finish	Voltage Rating	Center Contact Plating	Body Material	Operating Temperature (Min)	Operating Temperature (Max)	Mating Cycles	Dielectric Material
Radiall USA, Inc. R123464130	6000 MHz	Extended Insulation	Beryllium Copper	Flange	Solder	Snap-On	Panel Mount Through Hole	Gold	QMA	1	Female Socket Jack	50 Ohm	Solder	Gold	500 V	Gold	Brass	-40 °C	105 °C	100 cycles	Polytetrafluoroethylene (PTFE)
Radiall USA, Inc. R123464110	6000 MHz	Extended Insulation	Beryllium Copper	Flange	Solder	Snap-On	Panel Mount Through Hole	Gold	QMA	1	Female Socket Jack	50 Ohm	Solder	Gold	500 V	Gold	Brass	-40 °C	105 °C	100 cycles	Polytetrafluoroethylene (PTFE)
