DC0011/08-TI900-0.12-0

Active

t-Global Technology

THERM PAD 19.05MMX12.7MM WHT

Search across all available documentation for this part.

Active

t-Global Technology

THERM PAD 19.05MMX12.7MM WHT

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Thermal Pad White 19.05mm x 12.70mm Rectangular

Technical documentation and resources

Part	Usage	Shape	Color	Outline [x]	Outline [y]	Thermal Conductivity	Shelf Life	Thickness	Thickness	Type	Shelf Life Start	Material	Adhesive	Backing, Carrier	Thickness [x]	Thickness [x]	Thickness [custom]	Thickness [custom]
t-Global Technology DC0011/08-TG-A482K-0.1-0	TO-220	Rectangular	Red	19.05 mm	12.7 mm	2.3 W/m-K	24 Months	0.1 mm	0.0039 in	Die-Cut Pad, Sheet	Date of Purchase	Silicone
t-Global Technology DC0011/08-TI900-0.12-2A	TO-220	Rectangular	White	19.05 mm	12.7 mm	1.8 W/m-K	24 Months			Die-Cut Pad, Sheet		Silicone	Adhesive - Both Sides	Viscose	0.005 in	0.127 mm
t-Global Technology DC0011/08-TG-A486G-0.3-2A	TO-220	Rectangular	Gray	19.05 mm	12.7 mm	6 W/m-K	12 Months			Die-Cut Pad, Sheet	Date of Purchase		Adhesive - Both Sides				0.305 mm	0.012 "
t-Global Technology DC0011/08-TG-A373F-0.25-2A	TO-220	Rectangular	Yellow	19.05 mm	12.7 mm	1.4 W/m-K	12 Months			Die-Cut Pad, Sheet			Adhesive - Both Sides				0.254 mm	0.01 in
t-Global Technology DC0011/08-TI900-0.12-0	TO-220	Rectangular	White	19.05 mm	12.7 mm	1.8 W/m-K	24 Months			Die-Cut Pad, Sheet		Silicone		Viscose	0.005 in	0.127 mm
