FN2412H-16-44

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 520/300VAC 16A DIN

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 520/300VAC 16A DIN

Technical Specifications

Parameters and characteristics for this part

Specification	FN2412H-16-44

Applications	Regenerative Motor Drive
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	16 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Mounting Type	DIN Rail
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Terminal Block
Voltage - Rated AC	520 V, 300 V

Part	Frequency - Operating	Current	Filter Type	Voltage - Rated AC	Termination Style	Approval Agency	Applications	Operating Temperature [custom]	Configuration	Mounting Type
TE Connectivity Raychem Cable Protection FN2412-8-44	400 Hz	8 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412-16-44	400 Hz	16 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412H-16-44	400 Hz	16 A	Single Phase	300 V 520 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412-45-33	400 Hz	45 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412H-32-33	400 Hz	32 A	Single Phase	300 V 520 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	1	$ 83.60

General part information

Single Phase EMC/EMI Line Filter 16 A 520V, 300V DC ~ 400Hz Single Stage Terminal Block
