FN2412-16-44

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 16A DIN RAIL

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

LINE FILTER 250VAC 16A DIN RAIL

Technical Specifications

Parameters and characteristics for this part

Specification	FN2412-16-44

Applications	Regenerative Motor Drive
Approval Agency	CSA, ENEC, UR
Configuration	Single Stage
Current	16 A
Filter Type	Single Phase
Frequency - Operating	400 Hz
Mounting Type	DIN Rail
Operating Temperature [custom]	100 °C, -25 °C
Termination Style	Terminal Block
Voltage - Rated AC	250 V

Part	Frequency - Operating	Current	Filter Type	Voltage - Rated AC	Termination Style	Approval Agency	Applications	Operating Temperature [custom]	Configuration	Mounting Type
TE Connectivity Raychem Cable Protection FN2412-8-44	400 Hz	8 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412-16-44	400 Hz	16 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412H-16-44	400 Hz	16 A	Single Phase	300 V 520 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412-45-33	400 Hz	45 A	Single Phase	250 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail
TE Connectivity Raychem Cable Protection FN2412H-32-33	400 Hz	32 A	Single Phase	300 V 520 V	Terminal Block	CSA ENEC UR	Regenerative Motor Drive	-25 °C 100 °C	Single Stage	DIN Rail

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Single Phase EMC/EMI Line Filter 16 A 250V DC ~ 400Hz Single Stage Terminal Block
