E1225E12B1+3-FSR

Active

Mechatronics Fan Group

FAN AXIAL 120X25MM 12VDC WIRE

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDC Lead Wire Specs Datasheet +2

E1225E12B1+3-FSR

Active

Mechatronics Fan Group

FAN AXIAL 120X25MM 12VDC WIRE

Deep-Dive with AI

DocumentsDC Lead Wire Specs Datasheet +2

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 16.69

Description

General part information

E1225 Series

Fan Tubeaxial 12VDC Square - 120mm L x 120mm H Ball 93.0 CFM (2.60m³/min) 3 Wire Leads

Documents

Technical documentation and resources

DC Lead Wire Specs

Datasheet

DC Fan, Blower Lead Wire Spec

Datasheet

AC/DC Fans & Blowers Catalog

Datasheet

Specification	E1225E12B1+3-FSR	E1225 Series

Air Flow	93 CFM	44 - 93 CFM
Air Flow	2.6 m³/min	1.23 - 2.6 m³/min
Approval Agency	CE, cUL, TUV, UL	CE, cUL, TUV, UL
Bearing Type	Ball	Ball
Current Rating (Amps)	580 mA	0.142 - 600 mA
Fan Type	Tubeaxial	Tubeaxial
Features	Speed Sensor (Tach), Thermal Overload Protector (TOP), Thermistor	Thermal Overload Protector (TOP), Locked Rotor Sensor, Speed Sensor (Tach), Thermistor, Conformal Coating, PWM Control
Material - Blade	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT)
Noise	44 dB	28 - 44 dB
RPM	3000 RPM	1400 - 3000 RPM
Size / Dimension [x]	120 mm	120 mm
Size / Dimension [y]	120 mm	120 mm
Static Pressure	69.7 Pa	22.4 - 69.7 Pa
Static Pressure	0.28 in H2O	0.09 - 0.28 in H2O
Termination	3 Wire Leads	2 Wire Leads, 3 Wire Leads, 4 Wire Leads
Voltage - Rated	12 VDC	5 - 24 VDC
Weight	196.86 g	196.86 - 197.77 g
Weight	0.434 lb	0.434 - 0.436 lb
Width [y]	25 mm	25 mm

Part	Material - Blade	Approval Agency	Width [y]	Termination	Weight	Weight	Fan Type	Features	Air Flow	Air Flow	Voltage - Rated	Bearing Type	RPM	Size / Dimension [y]	Size / Dimension [x]	Static Pressure	Static Pressure	Noise	Current Rating (Amps)
Mechatronics Fan Group E1225M24B-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP)	67 CFM	1.88 m³/min	24 VDC	Ball	2200 RPM	120 mm	120 mm	44.8 Pa	0.18 in H2O	36 dB
Mechatronics Fan Group E1225M05B2-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	3 Wire Leads	197.77 g	0.436 lb	Tubeaxial	Locked Rotor Sensor, Thermal Overload Protector (TOP)	67 CFM	1.88 m³/min	5 V	Ball	2200 RPM	120 mm	120 mm	45 Pa	0.18 in H2O	36 dB	600 mA
Mechatronics Fan Group E1225L12B-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP)	55 CFM	1.54 mł/min	12 VDC	Ball	1800 RPM	120 mm	120 mm	29.9 Pa	0.12 in H2O	32 dB	0.142 A
Mechatronics Fan Group E1225E12B1+3-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	3 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Speed Sensor (Tach), Thermal Overload Protector (TOP), Thermistor	93 CFM	2.6 m³/min	12 VDC	Ball	3000 RPM	120 mm	120 mm	69.7 Pa	0.28 in H2O	44 dB	580 mA
Mechatronics Fan Group E1225E12B3-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP), Thermistor	93 CFM	2.6 m³/min	12 VDC	Ball	3000 RPM	120 mm	120 mm	69.7 Pa	0.28 in H2O	44 dB	580 mA
Mechatronics Fan Group E1225H12B-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP)	82 CFM	2.3 m³/min	12 VDC	Ball	2600 RPM	120 mm	120 mm	59.8 Pa	0.24 in H2O	40 dB(A)	385 mA
Mechatronics Fan Group E1225M05B-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP)	67 CFM	1.88 m³/min	5 V	Ball	2200 RPM	120 mm	120 mm	44.8 Pa	0.18 in H2O	36 dB	600 mA
Mechatronics Fan Group E1225L12B-FSR-CC	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	197.77 g	0.436 lb	Tubeaxial	Conformal Coating, Thermal Overload Protector (TOP)	55 CFM	1.54 mł/min	12 VDC	Ball	1800 RPM	120 mm	120 mm	29.9 Pa	0.12 in H2O	32 dB	0.142 A
Mechatronics Fan Group E1225E24B-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	2 Wire Leads	196.86 g	0.434 lb	Tubeaxial	Thermal Overload Protector (TOP)	93 CFM	2.6 m³/min	24 VDC	Ball	3000 RPM	120 mm	120 mm	69.7 Pa	0.28 in H2O	44 dB	0.34 A
Mechatronics Fan Group E1225S05B1-FSR	Polybutylene Terephthalate (PBT)	CE, cUL, TUV, UL	25 mm	3 Wire Leads	197.77 g	0.436 lb	Tubeaxial	Speed Sensor (Tach), Thermal Overload Protector (TOP)	44 CFM	1.23 m³/min	5 V	Ball	1400 RPM	120 mm	120 mm	22.4 Pa	0.09 in H2O	28 dB	0.22 A

Part

Material - Blade

Approval Agency

Width [y]

Termination

Weight

Fan Type

Features

Air Flow

Voltage - Rated

Bearing Type

RPM

Size / Dimension [y]

Size / Dimension [x]

Static Pressure

Noise

Current Rating (Amps)

Mechatronics Fan Group

E1225M24B-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP)

67 CFM

1.88 m³/min

24 VDC

Ball

2200 RPM

120 mm

44.8 Pa

0.18 in H2O

36 dB

Mechatronics Fan Group

E1225M05B2-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

3 Wire Leads

197.77 g

0.436 lb

Tubeaxial

Locked Rotor Sensor, Thermal Overload Protector (TOP)

67 CFM

1.88 m³/min

5 V

Ball

2200 RPM

120 mm

45 Pa

0.18 in H2O

36 dB

600 mA

Mechatronics Fan Group

E1225L12B-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP)

55 CFM

1.54 mł/min

12 VDC

Ball

1800 RPM

120 mm

29.9 Pa

0.12 in H2O

32 dB

0.142 A

Mechatronics Fan Group

E1225E12B1+3-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

3 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Speed Sensor (Tach), Thermal Overload Protector (TOP), Thermistor

93 CFM

2.6 m³/min

12 VDC

Ball

3000 RPM

120 mm

69.7 Pa

0.28 in H2O

44 dB

580 mA

Mechatronics Fan Group

E1225E12B3-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP), Thermistor

93 CFM

2.6 m³/min

12 VDC

Ball

3000 RPM

120 mm

69.7 Pa

0.28 in H2O

44 dB

580 mA

Mechatronics Fan Group

E1225H12B-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP)

82 CFM

2.3 m³/min

12 VDC

Ball

2600 RPM

120 mm

59.8 Pa

0.24 in H2O

40 dB(A)

385 mA

Mechatronics Fan Group

E1225M05B-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP)

67 CFM

1.88 m³/min

5 V

Ball

2200 RPM

120 mm

44.8 Pa

0.18 in H2O

36 dB

600 mA

Mechatronics Fan Group

E1225L12B-FSR-CC

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

197.77 g

0.436 lb

Tubeaxial

Conformal Coating, Thermal Overload Protector (TOP)

55 CFM

1.54 mł/min

12 VDC

Ball

1800 RPM

120 mm

29.9 Pa

0.12 in H2O

32 dB

0.142 A

Mechatronics Fan Group

E1225E24B-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

2 Wire Leads

196.86 g

0.434 lb

Tubeaxial

Thermal Overload Protector (TOP)

93 CFM

2.6 m³/min

24 VDC

Ball

3000 RPM

120 mm

69.7 Pa

0.28 in H2O

44 dB

0.34 A

Mechatronics Fan Group

E1225S05B1-FSR

Polybutylene Terephthalate (PBT)

CE, cUL, TUV, UL

25 mm

3 Wire Leads

197.77 g

0.436 lb

Tubeaxial

Speed Sensor (Tach), Thermal Overload Protector (TOP)

44 CFM

1.23 m³/min

5 V

Ball

1400 RPM

120 mm

22.4 Pa

0.09 in H2O

28 dB

0.22 A
