LMR-195-PVC

Active

Amphenol Times Microwave Systems

INDOOR CABLE, BLACK PVC JACKET

Deep-Dive with AI

Search across all available documentation for this part.

LMR-195-PVC

Active

Amphenol Times Microwave Systems

INDOOR CABLE, BLACK PVC JACKET

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	5	$ 446.98

Description

General part information

LMR-195 Series

Coaxial Cable 50 Ohms

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	LMR-195-PVC	LMR-195 Series

Cable Type	Coaxial	Coaxial, Coaxial - Riser, Coaxial - Plenum
Conductor Material	Copper, Bare	Copper, Bare
Conductor Strand	Solid	Solid
Dielectric Diameter	-	2.87 mm
Dielectric Diameter	-	0.113 "
Dielectric Diameter [diameter]	2.79 mm	2.79 mm
Dielectric Diameter [diameter]	0.11 in	0.11 in
Dielectric Material	Foam Polyethylene (FPE)	Foam Polyethylene (FPE), Polytetrafluoroethylene (PTFE)
Features	-	Fire Retardant, Direct Burial, Watertight
Impedance	50 Ohms	50 Ohms
Jacket (Insulation) Diameter [diameter]	0.195 in	0.175 - 0.195 in
Jacket (Insulation) Diameter [diameter]	4.95 mm	4.45 - 4.95 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)	Thermoplastic Elastomer (TPE), Polyethylene (PE), Riser, Poly-Vinyl Chloride (PVC), Poly-Vinyl Chloride (PVC), Riser, Polyethylene (PE), Fluoropolymer, Plenum, Low Smoke Zero Halogen (LSZH)
Jacket Color	Black	Black, Red
Length	-	Enter Number of Feet in Order Quantity
Length	-	1 - 100 ft
Length	-	3.05 - 300 mm
Length	-	15.24 m
Length	-	50 ft
Operating Temperature [Max]	85 °C	85 - 125 °C
Operating Temperature [Min]	-40 °C	-40 °C
Shield Material	Copper, Tinned, Aluminum	Copper, Tinned, Aluminum
Shield Type	Braid	Foil, Braid
Spool Size	-	500 '
Spool Size	-	152.4 m
Usage	-	Antenna
VoP, Velocity of Propagation	80	74 - 80

LMR-195 Series

LMR-195 W/STRAND CTR CONDUC FOOT

Part	Impedance	Length	Dielectric Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket Color	VoP, Velocity of Propagation	Shield Type	Operating Temperature [Max]	Operating Temperature [Min]	Dielectric Diameter [diameter]	Dielectric Diameter [diameter]	Jacket (Insulation) Material	Spool Size	Spool Size	Conductor Material	Cable Type	Shield Material	Features	Conductor Strand	Usage	Dielectric Diameter	Dielectric Diameter	Length [x]	Length [x]
Amphenol Times Microwave Systems LMR-195-UF	50 Ohms	Enter Number of Feet in Order Quantity	Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	74	Braid, Foil	85 °C	-40 °C	2.79 mm	0.11 in	Thermoplastic Elastomer (TPE)	500 '	152.4 m	Copper, Bare	Coaxial	Aluminum, Copper, Tinned
Amphenol Times Microwave Systems LMR-195-FR-W	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm		80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Polyethylene (PE), Riser			Copper, Bare	Coaxial - Riser	Aluminum, Copper, Tinned	Fire Retardant	Solid
Amphenol Times Microwave Systems LMR-195-MA	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Poly-Vinyl Chloride (PVC)			Copper, Bare	Coaxial	Aluminum, Copper, Tinned		Solid	Antenna
Amphenol Times Microwave Systems LMR-195-FR-PVC	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Poly-Vinyl Chloride (PVC), Riser			Copper, Bare	Coaxial - Riser	Aluminum, Copper, Tinned	Fire Retardant	Solid
Amphenol Times Microwave Systems LMR-195-DB	50 Ohms	Enter Number of Feet in Order Quantity	Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Polyethylene (PE)	500 '	152.4 m	Copper, Bare	Coaxial	Aluminum, Copper, Tinned	Direct Burial, Watertight	Solid
Amphenol Times Microwave Systems LMR-195-PVC-W	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm		80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Poly-Vinyl Chloride (PVC)			Copper, Bare	Coaxial	Aluminum, Copper, Tinned		Solid
Amphenol Times Microwave Systems LMR-195-PVC	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Poly-Vinyl Chloride (PVC)			Copper, Bare	Coaxial	Aluminum, Copper, Tinned		Solid
Amphenol Times Microwave Systems LMR-195-LLPX	50 Ohms		Polytetrafluoroethylene (PTFE)	0.175 in	4.45 mm	Red	76	Braid, Foil	125 °C	-40 °C			Fluoropolymer, Plenum			Copper, Bare	Coaxial - Plenum	Aluminum, Copper, Tinned		Solid		2.87 mm	0.113 "
Amphenol Times Microwave Systems LMR-195-FR	50 Ohms	Enter Number of Feet in Order Quantity	Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	80	Braid	85 °C	-40 °C	2.79 mm	0.11 in	Polyethylene (PE), Riser	500 '	152.4 m	Copper, Bare	Coaxial - Riser	Aluminum, Copper, Tinned	Fire Retardant	Solid
Amphenol Times Microwave Systems LMR-195-LSZH	50 Ohms		Foam Polyethylene (FPE)	0.195 in	4.95 mm	Black	76	Braid	85 °C	-40 °C			Low Smoke Zero Halogen (LSZH), Polyethylene (PE)			Copper, Bare	Coaxial	Aluminum, Copper, Tinned		Solid		2.87 mm	0.113 "	1 ft	300 mm
