SM72480 Series

Catalog

BOARD MOUNT TEMPERATURE SENSORS 1.6V LLP-6 FACTORY PRESET TEMPERATURE S A 926-L26LVCISDX120NPB

Part	Output Type	Output Function	Package / Case	Current - Supply	Package Width	Package Name	Package Length	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Output	Operating Temperature (Min)	Operating Temperature (Max)	Current - Output (Max)	Switching Temperature	Mounting Type	Trip Temperature Threshold	Selectable Hysteresis	Accuracy
Texas Instruments SM72480SDX-120/NOPB
Texas Instruments SM72480SDX-105/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	221 °F	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SDE-125/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	257 °F	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SDE-120/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	120 °C	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SD-105/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	221 °F	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SDX-125/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	257 °F	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SD-125/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	257 °F	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SDE-105/NOPB
Texas Instruments SM72480SD-120/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	120 °C	Surface Mount	Hot	No	2.2 °C
Texas Instruments SM72480SD-120/NOPB	Open Drain Push-Pull	/OverTemp OverTemp	6-WDFN Exposed Pad	8 µA	2.5 mm	6-WSON	2.2 mm	5.5 V	1.6 V	Active High Active Low	-50 °C	150 °C	7 mA	120 °C	Surface Mount	Hot	No	2.2 °C
