TMS320VC5501 Series
Manufacturer: Texas Instruments
Beta
⌘K
LOW POWER C55X FIXED POINT DSP- UP TO 300MHZ
| Part | Voltage - Core | Clock Rate (Frequency) | Type | Interface | Non-Volatile Memory Size | Non-Volatile Memory Type | Mounting Type | Voltage - I/O | Package / Case | Operating Temperature (Min) | Operating Temperature (Max) | On-Chip RAM | Package Name | Package Width | Package Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 1.26 V | 300 MHz | Fixed Point | Host Interface I2C McBSP UART | 32 kB | ROM | Surface Mount | 3.3 V | 201-LFBGA | -40 °C | 85 °C | 48 kB | 201-BGA MICROSTAR | 15 mm | 15 mm |
 Texas Instruments | 1.26 V | 300 MHz | Fixed Point | Host Interface I2C McBSP UART | 32 kB | ROM | Surface Mount | 3.3 V | 176-LQFP | -40 °C | 85 °C | 48 kB | 176-LQFP | 24 mm | 24 mm |
