TLV70030 Series

Catalog

IC REG LINEAR 3V 200MA 6WSON

Part	Output Type	Protection Features	PSRR	Package Length	Package Name	Package Width	Voltage - Output (Min/Fixed)	Control Features	Current - Supply (Max)	Current - Output	Current - Quiescent (Iq)	Voltage Dropout (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Voltage - Input (Max)	Output Configuration	Number of Regulators	Package / Case	Grade	Qualification
Texas Instruments TLV70030DSET	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB	1.5 mm	6-WSON	1.5 mm	3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	6-WFDFN
Texas Instruments TLV70030DCKT	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB		SC-70-5		3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	5-TSSOP SC-70-5 SOT-353
Texas Instruments TLV70030QDCKRQ1	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB		SC-70-5		3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	5-TSSOP SC-70-5 SOT-353	Automotive	AEC-Q100
Texas Instruments TLV70030DDCR	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB		SOT-23-THIN		3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	SOT-23-5 Thin TSOT-23-5
Texas Instruments TLV70030DDCT	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB		SOT-23-THIN		3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	SOT-23-5 Thin TSOT-23-5
Texas Instruments TLV70030DSER	Fixed	Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO)	68 dB	1.5 mm	6-WSON	1.5 mm	3 V	Enable	270 µA	200 mA	55 µA	0.25 V	125 °C	-40 °C	Surface Mount	5.5 V	Positive	1	6-WFDFN
