LM4809 Series

Catalog

105-MW, STEREO, ANALOG INPUT HEADPHONE AMPLIFIER WITH ACTIVE-LOW SHUTDOWN MODE

Part	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Package Name	Package Width	Package Length	Load Impedance	Maximum Output Power (per Channel)	Channels	Package / Case	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Type	Features	Output Type	Board Type	Supplied Contents	Contents	Utilized IC / Part	Amplifier Type
Texas Instruments LM4809LDX/NOPB	85 °C	-40 °C	Surface Mount	8-WSON	2.5 mm	2.5 mm	16 Ohm	105 mW	2	8-WFDFN Exposed Pad	5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809MBD							16 Ohm	105 mW	2		5.5 V	2 V			2-Channel (Stereo) Headphones	Fully Populated	Board(s)	Board	LM4809	Class AB
Texas Instruments LM4809MA/NOPB	85 °C	-40 °C	Surface Mount	8-SOIC	3.9 mm	0.154 in	16 Ohm	105 mW	2		5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809MM/NOPB	85 °C	-40 °C	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	3 mm	0.118 in	16 Ohm	105 mW	2		5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809MM/NOPB	85 °C	-40 °C	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	3 mm	0.118 in	16 Ohm	105 mW	2		5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809LQX/NOPB	85 °C	-40 °C	Surface Mount	8-WQFN	2 mm	2 mm	16 Ohm	105 mW	2	8-WQFN Exposed Pad	5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809MM	85 °C	-40 °C	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	3 mm	0.118 in	16 Ohm	105 mW	2		5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
Texas Instruments LM4809LDBD							16 Ohm	105 mW	2		5.5 V	2 V			2-Channel (Stereo) Headphones	Fully Populated	Board(s)	Board	LM4809	Class AB
Texas Instruments LM4809LQ/NOPB	85 °C	-40 °C	Surface Mount	8-WQFN	2 mm	2 mm	16 Ohm	105 mW	2	8-WQFN Exposed Pad	5.5 V	2 V	Class AB	Depop Shutdown Thermal Protection	2-Channel (Stereo) Headphones
