LP8340 Series

Catalog

IC REG LINEAR 2.5V 1A TO252-3

Part	Voltage - Input (Max)	Mounting Type	Output Type	Voltage Dropout (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Supply (Max)	Protection Features	Current - Quiescent (Iq)	Number of Regulators	Package Name	Output Configuration	Voltage - Output (Min/Fixed)	PSRR	Package / Case	Current - Output	Voltage - Output (Max)	Package Length	Package Width
Texas Instruments LP8340IDT-2.5/NOPB	10 V	Surface Mount	Fixed	1.5 V	125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	TO-252-3	Positive	2.5 V	55 dB	DPAK (2 Leads + Tab) SC-63 TO-252-3	1 A
Texas Instruments LP8340ILDX-ADJ	10 V	Surface Mount	Adjustable		125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	6-WSON	Positive	1.25 V	55 dB	6-WDFN Exposed Pad	1 A	9.3 V	2.92 mm	3.29 mm
Texas Instruments LP8340IDT-5.0/NOPB	10 V	Surface Mount	Fixed	0.8 V	125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	TO-252-3	Positive	5 V	55 dB	DPAK (2 Leads + Tab) SC-63 TO-252-3	1 A
Texas Instruments LP8340CDT-5.0/NOPB	10 V	Surface Mount	Fixed	0.8 V	125 °C	0 °C	170 µA	Over Current Over Temperature	100 µA	1	TO-252-3	Positive	5 V	55 dB	DPAK (2 Leads + Tab) SC-63 TO-252-3	1 A
Texas Instruments LP8340ILDX-ADJ/NOPB	10 V	Surface Mount	Adjustable		125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	6-WSON	Positive	1.25 V	55 dB	6-WDFN Exposed Pad	1 A	9.3 V	2.92 mm	3.29 mm
Texas Instruments LP8340ILDX-ADJ/NOPB	10 V	Surface Mount	Adjustable		125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	6-WSON	Positive	1.25 V	55 dB	6-WDFN Exposed Pad	1 A	9.3 V	2.92 mm	3.29 mm
Texas Instruments LP8340CLDX-2.5/NOPB	10 V	Surface Mount	Fixed	1.5 V	125 °C	0 °C	170 µA	Over Current Over Temperature	100 µA	1	6-WSON	Positive	2.5 V	55 dB	6-WDFN Exposed Pad	1 A		2.92 mm	3.29 mm
Texas Instruments LP8340CDT-1.8/NOPB	10 V	Surface Mount	Fixed	1.4 V	125 °C	0 °C	170 µA	Over Current Over Temperature	100 µA	1	TO-252-3	Positive	1.8 V	55 dB	DPAK (2 Leads + Tab) SC-63 TO-252-3	1 A
Texas Instruments LP8340ILD-3.3/NOPB	10 V	Surface Mount	Fixed	1 V	125 °C	-40 °C	170 µA	Over Current Over Temperature	100 µA	1	6-WSON	Positive	3.3 V	55 dB	6-WDFN Exposed Pad	1 A		2.92 mm	3.29 mm
Texas Instruments LP8340CDT-2.5/NOPB	10 V	Surface Mount	Fixed	1.5 V	125 °C	0 °C	170 µA	Over Current Over Temperature	100 µA	1	TO-252-3	Positive	2.5 V	55 dB	DPAK (2 Leads + Tab) SC-63 TO-252-3	1 A
