ADS1216 Series

Catalog

IC ADC 24BIT SIGMA-DELTA 48TQFP

Part	Sampling Rate (Per Second)	Architecture	Voltage - Supply, Analog (Typical)	Voltage - Supply, Analog (Additional)	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Package / Case	Number of Inputs	Reference Type	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Number of A/D Converters	Number of Bits	Package Length	Package Name	Package Width	Features	Mounting Type	Data Interface	Input Type	Configuration
Texas Instruments ADS1216Y/2KG4	780 Hz	Sigma-Delta	5 V	5 V	2.7 V	3.3 V	48-TQFP	8	External Internal	2.7 V	5.25 V	-40 °C	85 °C	1 count	24 bits	7 mm	48-TQFP	7 mm	PGA	Surface Mount	SPI	Differential	MUX-PGA-ADC
Texas Instruments ADS1216Y/2K	780 Hz	Sigma-Delta			2.85 V	5.25 V	48-TQFP	8	External Internal	2.95 V	5.25 V	-40 °C	85 °C	1 count	24 bits	7 mm	48-TQFP	7 mm	PGA	Surface Mount	SPI	Differential	MUX-PGA-ADC
Texas Instruments ADS1216Y/250	780 Hz	Sigma-Delta	5 V	5 V	2.7 V	3.3 V	48-TQFP	8	External Internal	2.7 V	5.25 V	-40 °C	85 °C	1 count	24 bits	7 mm	48-TQFP	7 mm	PGA	Surface Mount	SPI	Differential	MUX-PGA-ADC
