DS80PCI800 Series
Manufacturer: Texas Instruments
Beta
⌘K
2.5/5.0/8.0-GBPS 8-CHANNEL PCI EXPRESS REDRIVER WITH EQUALIZATION & DE-EMPHASIS
| Part | Package / Case | Input | Mounting Type | Data Rate (Max) | Capacitance - Input | Operating Temperature (Min) | Operating Temperature (Max) | Type | Voltage - Supply (Minimum) | Voltage - Supply (Maximum) | Number of Channels | Delay Time | Package Name | Package Length | Package Width | Output | Applications | Signal Conditioning | Supplied Contents | Contents | Function | Utilized IC / Part |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 54-WFQFN Exposed Pad | CML | Surface Mount | 8 Gbps | 10 pF | -40 °C | 85 °C | Buffer ReDriver | 2.375 V | 3.6 V | 8 | 200 ps | 54-WQFN | 10 mm | 5.5 mm | CML | PCIe | Input Equalization Output De-Emphasis | ||||
 Texas Instruments | Interface | Board(s) | Board | PCI Express Transceiver | DS80PCI800 | |||||||||||||||||
 Texas Instruments | Interface | Board(s) | Board | PCI Express Transceiver | DS80PCI800 | |||||||||||||||||
Texas Instruments | 54-WFQFN Exposed Pad | CML | Surface Mount | 8 Gbps | 10 pF | -40 °C | 85 °C | Buffer ReDriver | 2.375 V | 3.6 V | 8 | 200 ps | 54-WQFN | 10 mm | 5.5 mm | CML | PCIe | Input Equalization Output De-Emphasis |
