ADS7800 Series

Catalog

IC ADC 12BIT SAR 24DIP

Part	Architecture	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Typical)	Data Interface	Configuration	Operating Temperature (Min)	Operating Temperature (Max)	Ratio - ADC	Ratio - S/H	Number of Inputs	Sampling Rate (Per Second)	Mounting Type	Number of Bits	Number of A/D Converters	Voltage - Supply, Digital	Reference Type	Package Width	Package Name	Package Length	Input Type
Texas Instruments ADS7800JPG4	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-DIP 24-PDIP	0.3 in	Single Ended
Texas Instruments ADS7800JP	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-DIP 24-PDIP	0.3 in	Single Ended
Texas Instruments ADS7800JP	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-DIP 24-PDIP	0.3 in	Single Ended
Texas Instruments ADS7800BH	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-CDIP	0.3 in	Single Ended
Texas Instruments ADS7800KP	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-DIP 24-PDIP	0.3 in	Single Ended
Texas Instruments ADS7800JU/1K	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Surface Mount	12 bits	1 count	5 V	Internal	7.5 mm	24-SOIC	0.295 in	Single Ended
Texas Instruments ADS7800KU	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Surface Mount	12 bits	1 count	5 V	Internal	7.5 mm	24-SOIC	0.295 in	Single Ended
Texas Instruments ADS7800AH	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Through Hole	12 bits	1 count	5 V	Internal	7.62 mm	24-CDIP	0.3 in	Single Ended
Texas Instruments ADS7800KU/1K	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Surface Mount	12 bits	1 count	5 V	Internal	7.5 mm	24-SOIC	0.295 in	Single Ended
Texas Instruments ADS7800KUG4	SAR	16.5 V	-11.4 V	5 V	Parallel	S/H-ADC	-40 °C	85 °C	1	1	1	333 kHz	Surface Mount	12 bits	1 count	5 V	Internal	7.5 mm	24-SOIC	0.295 in	Single Ended
