CC2651 Series

The SimpleLink™ CC2651P3 device is a single-protocol 2.4-GHz wireless microcontroller (MCU) supportingZigbee,Bluetooth5.2 Low Energy, IEEE 802.15.4g,TI 15.4-Stack(2.4 GHz). The CC2651P3 is based on an Arm®Cortex®M4 main processor and optimized for low-power wireless communication and advanced sensing ingrid infrastructure,building automation,retail automation,personal electronicsandmedical applications. The CC2651P3 has a software defined radio powered by an Arm® Cortex® M0, which allows support for multiple physical layers and RF standards. The device supports operation in the 2360 to 2500-MHz frequency band. The CC2651P3 has an efficient built-in PA that supports +10 dBm TX at 21 mA and +20 dBm TX at 101 mA (7x7 package). CC2651P3 has a receive sensitivity of -104 dBm for 125-kbps Bluetooth® Low Energy Coded PHY. The CC2651P3 has a low sleep current of 0.8 µA with RTC and 32KB RAM retention. Consistent with many customers’ 10 to 15 years or longer life cycle requirements, TI has aproduct life cycle policywith a commitment to product longevity and continuity of supply. The CC2651P3 device is part of the SimpleLink™ MCU platform, which consists of Wi-Fi®,Bluetooth®Low Energy, Thread, Zigbee, Wi-SUN®, Amazon Sidewalk,mioty, Sub-1 GHz MCUs, and host MCUs. CC2651P3 is part of a scalable portfolio with flash sizes from 32KB to 704KB with pin-to-pin compatible package options. The commonSimpleLink™CC13xx and CC26xx Software Development Kit (SDK)andSysConfigsystem configuration tool supports migration between devices in the portfolio. A comprehensive number of software stacks, application examples and SimpleLink™ Academy training sessions are included in the SDK. For more information, visitwireless connectivity. The SimpleLink™ CC2651P3 device is a single-protocol 2.4-GHz wireless microcontroller (MCU) supportingZigbee,Bluetooth5.2 Low Energy, IEEE 802.15.4g,TI 15.4-Stack(2.4 GHz). The CC2651P3 is based on an Arm®Cortex®M4 main processor and optimized for low-power wireless communication and advanced sensing ingrid infrastructure,building automation,retail automation,personal electronicsandmedical applications. The CC2651P3 has a software defined radio powered by an Arm® Cortex® M0, which allows support for multiple physical layers and RF standards. The device supports operation in the 2360 to 2500-MHz frequency band. The CC2651P3 has an efficient built-in PA that supports +10 dBm TX at 21 mA and +20 dBm TX at 101 mA (7x7 package). CC2651P3 has a receive sensitivity of -104 dBm for 125-kbps Bluetooth® Low Energy Coded PHY. The CC2651P3 has a low sleep current of 0.8 µA with RTC and 32KB RAM retention. Consistent with many customers’ 10 to 15 years or longer life cycle requirements, TI has aproduct life cycle policywith a commitment to product longevity and continuity of supply. The CC2651P3 device is part of the SimpleLink™ MCU platform, which consists of Wi-Fi®,Bluetooth®Low Energy, Thread, Zigbee, Wi-SUN®, Amazon Sidewalk,mioty, Sub-1 GHz MCUs, and host MCUs. CC2651P3 is part of a scalable portfolio with flash sizes from 32KB to 704KB with pin-to-pin compatible package options. The commonSimpleLink™CC13xx and CC26xx Software Development Kit (SDK)andSysConfigsystem configuration tool supports migration between devices in the portfolio. A comprehensive number of software stacks, application examples and SimpleLink™ Academy training sessions are included in the SDK. For more information, visitwireless connectivity.
