TIOL1113 Series
Manufacturer: Texas Instruments
Beta
⌘K
IO-LINK DEVICE TRANSCEIVER WITH INTEGRATED SURGE PROTECTION AND 3.3-V LDO OUTPUT
| Part | Receiver Hysteresis | Operating Temperature (Max) | Operating Temperature (Min) | Mounting Type | Type | Package Name | Package Width | Package Length | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Data Rate | Number of Drivers | Number of Receivers | Protocol | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 750 mV | 125 °C | -40 °C | Surface Mount | Transceiver | 10-VSON | 3 mm | 2.5 mm | 36 VDC | 7 V | 250 Kbps | 1 | 1 | I O-Link | 10-VFDFN Exposed Pad |
 Texas Instruments | 750 mV | 125 °C | -40 °C | Surface Mount | Transceiver | 10-VSON | 3 mm | 2.5 mm | 36 VDC | 7 V | 250 Kbps | 1 | 1 | I O-Link | 10-VFDFN Exposed Pad |
