LM3407 Series
Manufacturer: Texas Instruments
Beta
⌘K
350-MA CONSTANT, CONSTANT CURRENT OUTPUT FLOATING BUCK SWITCHING CONVERTER FOR HIGH POWER LEDS
| Part | Applications | Number of Outputs | Internal Switch(s) | Voltage - Supply (Min) | Operating Temperature (Max) | Operating Temperature (Min) | Frequency (Max) | Frequency (Min) | Mounting Type | Package Length | Package Name | Package Width | Dimming | Voltage - Supply (Max) | Current - Output / Channel | Topology | Type | Supplied Contents | Features | Voltage - Output | Contents | Utilized IC / Part | Voltage - Input (Maximum) | Voltage - Input (Minimum) | Total Output Count | Output Type | Non-Isolated Output Count |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Lighting | 1 | Yes | 4.5 V | 125 °C | -40 °C | 1 MHz | 300 kHz | Surface Mount | 0.118 in | 8-HVSSOP 8-MSOP 8-PowerTSSOP | 3 mm | PWM | 30 V | 350 mA | Step-Down (Buck) | DC DC Regulator | ||||||||||
 Texas Instruments | 350 mA | Board(s) | Dimmable | 4.5 V | Board | LM3407 | 30 V | 4.5 V | 1 | Non-Isolated | 1 count | ||||||||||||||||
Texas Instruments | Lighting | 1 | Yes | 4.5 V | 125 °C | -40 °C | 1 MHz | 300 kHz | Surface Mount | 0.118 in | 8-HVSSOP 8-MSOP 8-PowerTSSOP | 3 mm | PWM | 30 V | 350 mA | Step-Down (Buck) | DC DC Regulator | ||||||||||
 Texas Instruments | 350 mA | Board(s) | Dimmable | 4.5 V | Board | LM3407 | 30 V | 4.5 V | 1 | Non-Isolated | 1 count |
