TMP144 Series

Catalog

TEMPERATURE SENSOR DEVELOPMENT TOOLS TMP144 EVALUATION MO DULE

Part	Supplied Contents	Interface	Embedded Bit Width	Embedded	Sensor Type	Voltage - Supply	Voltage - Supply Type	Contents	Utilized IC / Part	Mounting Type	Sensing Temperature - Local (Max)	Sensing Temperature - Local (Min)	Package Name	Package / Case	Resolution	Accuracy - Highest	Accuracy - Lowest	Test Condition (Primary) Maximum	Test Condition (Primary) Minimum	Test Condition (Alternate) Minimum	Test Condition (Alternate) Maximum	Operating Temperature (Max)	Operating Temperature (Min)	Output Type	Voltage - Supply (Maximum)	Voltage - Supply (Minimum)	Features	Package Length	Package Width	Sensing Temperature - Remote (Min)	Sensing Temperature - Remote (Max)
Texas Instruments TMP144EVM	Board(s)	Digital	16 bit	MCU Yes	Temperature	5 VDC	USB	Board	TMP144
Texas Instruments TMP144YFFR					Digital Local					Surface Mount	125 °C	-40 °C	4-DSBGA	4-UFBGA DSBGA	12 b	1 °C	2 °C	100 ¯C	-10 °C	-40 °C	125 ¯C	125 °C	-40 °C	SMAART Wire UART	3.6 V	1.4 V	One-Shot Shutdown Mode
Texas Instruments TMP144YMTR					Digital Local					Surface Mount	125 °C	-40 °C	4-Picostar	4-XFBGA DSBGA	12 b	1 °C	2 °C	100 ¯C	-10 °C	-40 °C	125 ¯C	125 °C	-40 °C	SMAART Wire UART	3.6 V	1.4 V	One-Shot Shutdown Mode Standby Mode	0.76 mm	0.76 mm
Texas Instruments TMP144YMTT					Digital Local					Surface Mount	125 °C	-40 °C	4-Picostar	4-XFBGA DSBGA	12 b	1 °C	2 °C	100 ¯C	-10 °C	-40 °C	125 ¯C	125 °C	-40 °C	SMAART Wire UART	3.6 V	1.4 V	One-Shot Shutdown Mode Standby Mode	0.76 mm	0.76 mm
Texas Instruments TMP144YFFT					Digital Local					Surface Mount	125 °C	-40 °C	4-DSBGA	4-UFBGA DSBGA	12 b	1 °C	2 °C	100 ¯C	-10 °C	-40 °C	125 ¯C	125 °C	-40 °C	SMAART Wire UART	3.6 V	1.4 V	One-Shot Shutdown Mode
Texas Instruments TMP144YBKR					Digital					Surface Mount	125 °C	-40 °C	4-DSBGA	4-XFBGA DSBGA	12 b	1 °C	2 °C	100 ¯C	-10 °C	-40 °C	125 ¯C	125 °C	-40 °C	SMAART Wire UART	3.6 V	1.4 V	One-Shot Shutdown Mode	0.8 mm	1 mm	-10 °C	100 °C
