SN74LV6T06-EP Series
Manufacturer: Texas Instruments
Beta
⌘K
ENHANCED-PRODUCT, SIX-BIT INVERTING OPEN-DRAIN FIXED-DIRECTION LEVEL TRANSLATOR
| Part | Package Width | Package Name | Package Length | Mounting Type | Output Type | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Number of Elements | Operating Temperature (Max) | Operating Temperature (Min) | Logic Type | Number of Bits per Element | Current - Output Low | Translator Type | Voltage - VCCB (Max) | Voltage - VCCB (Min) | Channel Type | Data Rate | Number of Circuits | Voltage - VCCA (Max) | Voltage - VCCA (Min) | Channels per Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 4.4 mm | 14-TSSOP | 0.173 in | Surface Mount | Open Drain | 5.5 V | 1.6 V | 6 | 125 °C | -55 °C | Buffer Non-Inverting | 1 bits | 8 mA | |||||||||
Texas Instruments | 4.4 mm | 14-TSSOP | 0.173 in | Surface Mount | Open Drain | 125 °C | -55 °C | Voltage Level | 5.5 V | 1.65 V | Unidirectional | 150 MHz | 6 | 5.5 V | 1 V | 1 |
