LM4864 Series
Manufacturer: Texas Instruments
Beta
⌘K
IC AMP CLASS AB MONO 725MW 8DIP
| Part | Type | Mounting Type | Output Type | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Features | Package Name | Package Length | Package Width | Load Impedance | Channels | Maximum Output Power (per Channel) | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | Class AB | Through Hole | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-DIP 8-PDIP | 0.3 in | 7.62 mm | 8 Ohm | 1 | 725 mW | |
 Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 3 mm | 8 Ohm | 1 | 675 mW | |
 Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 10-WSON | 3 mm | 3 mm | 8 Ohm | 1 | 725 mW | 10-WFDFN Exposed Pad |
 Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-SOIC | 0.154 in | 3.9 mm | 8 Ohm | 1 | 675 mW | |
 Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 3 mm | 8 Ohm | 1 | 675 mW | |
Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-TSSOP 8-MSOP 8-VSSOP | 0.118 in | 3 mm | 8 Ohm | 1 | 675 mW | |
Texas Instruments | Class AB | Through Hole | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-DIP 8-PDIP | 0.3 in | 7.62 mm | 8 Ohm | 1 | 725 mW | |
 Texas Instruments | Class AB | Surface Mount | 1-Channel (Mono) | 85 °C | -40 °C | 5.5 V | 2.7 V | Shutdown Thermal Protection | 8-SOIC | 0.154 in | 3.9 mm | 8 Ohm | 1 | 675 mW |
