ADS54T01 Series

Catalog

1-CHANNEL SINGLE ADC PIPELINED 750MSPS 12-BIT PARALLEL 196-PIN NFBGA TRAY

Part	Package Name	Package Length	Package Width	Configuration	Number of Inputs	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Package / Case	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 1 Min)	Operating Temperature (Min)	Operating Temperature (Max)	Number of A/D Converters	Number of Bits	Sampling Rate (Per Second)	Mounting Type	Architecture	Ratio - ADC	Ratio - S/H	Input Type	Reference Type	Data Interface
Texas Instruments ADS54T01IZAY	196-NFBGA	12 mm	12 mm	S/H-ADC	1	1.7 V	1.9 V	196-LFBGA	1.9 V	3.45 V	3.15 V	1.7 V	-40 °C	85 °C	1 count	12 bits	750 MHz	Surface Mount	Pipelined	1	1	Differential	Internal	LVDS - Parallel
Texas Instruments ADS54T01IZAYR	196-NFBGA	12 mm	12 mm	S/H-ADC	1	1.7 V	1.9 V	196-LFBGA	1.9 V	3.45 V	3.15 V	1.7 V	-40 °C	85 °C	1 count	12 bits	750 MHz	Surface Mount	Pipelined	1	1	Differential	Internal	LVDS - Parallel
