LM4570 Series

Catalog

BOARD EVAL FOR LM4570LQ

Part	Supplied Contents	Contents	Function	Type	Utilized IC / Part	Current - Output	Motor Type - AC, DC	Package Name	Package Width	Package Length	Technology	Mounting Type	Package / Case	Interface	Applications	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Half-Bridge Count	Output Configuration	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Load (Max)	Voltage - Load (Min)
Texas Instruments LM4570LQBD/NOPB	Board(s)	Board	Haptic/Vibration Motor Controller/Driver	Power Management	LM4570
Texas Instruments LM4570LQX/NOPB			Control and Power Stage Driver - Fully Integrated			192 mA	Brushed DC	8-WQFN	2 mm	2 mm	Power MOSFET	Surface Mount	8-WQFN Exposed Pad	Parallel	General Purpose	2.4 V	5.5 V	2	Half Bridge	-40 °C	150 °C	5.5 V	2.4 V
Texas Instruments LM4570LQ/NOPB			Control and Power Stage Driver - Fully Integrated			192 mA	Brushed DC	8-WQFN	2 mm	2 mm	Power MOSFET	Surface Mount	8-WQFN Exposed Pad	Parallel	General Purpose	2.4 V	5.5 V	2	Half Bridge	-40 °C	150 °C	5.5 V	2.4 V
Texas Instruments LM4570LQ/NOPB			Control and Power Stage Driver - Fully Integrated			192 mA	Brushed DC	8-WQFN	2 mm	2 mm	Power MOSFET	Surface Mount	8-WQFN Exposed Pad	Parallel	General Purpose	2.4 V	5.5 V	2	Half Bridge	-40 °C	150 °C	5.5 V	2.4 V
Texas Instruments LM4570LQX/NOPB			Control and Power Stage Driver - Fully Integrated			192 mA	Brushed DC	8-LLP-EP	2 mm	2 mm	Power MOSFET	Surface Mount	8-WQFN Exposed Pad	Parallel	General Purpose	2.4 V	5.5 V	2	Half Bridge	-40 °C	150 °C	5.5 V	2.4 V
