LMZ21701 Series
Manufacturer: Texas Instruments
Beta
⌘K
3V TO 17V, 1A STEP-DOWN DC/DC POWER MODULE IN 3.5MM × 3.5MM PACKAGE
| Part | Voltage - Input (Min) | Efficiency | Type | Operating Temperature (Max) | Operating Temperature (Min) | Size / Dimension Height | Size / Dimension Length | Size / Dimension Width | Current - Output (Max) | Mounting Type | Voltage - Input (Max) | Package / Case | Control Features | Features | Number of Outputs | Applications | Voltage - Output 1 (Max) | Voltage - Output 1 (Min) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 3 V | 95 % | Non-Isolated PoL Module | 125 °C | -40 °C | 0.07 in | 0.14 in | 0.14 in | 1 A | Surface Mount | 17 V | 8-SMD Module | Active High Enable | OTP SCP UVLO | 1 | ITE (Commercial) | 6 V | 0.9 V |
 Texas Instruments | 3 V | 95 % | Non-Isolated PoL Module | 125 °C | -40 °C | 0.07 in | 0.14 in | 0.14 in | 1 A | Surface Mount | 17 V | 8-SMD Module | Active High Enable | OCP OTP SCP UVLO | 1 | ITE (Commercial) | 6 V | 0.9 V |
