DAC81408 Series

Catalog

DATA CONVERSION IC DEVELOPMENT TOOLS DAC81408EVM

Part	Settling Time	Supplied Contents	Number of Bits	Data Interface	DAC Type	Contents	Utilized IC / Part	Number of DAC's	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Mounting Type	Reference Type	INL (LSB) Tolerance	DNL (LSB) Tolerance	Voltage - Supply, Analog (Max)	Voltage - Supply, Analog (Min)	Number of D/A Converters	Package / Case	Architecture	Package Width	Package Name	Package Length	Differential Output	Settling Time (Typical)	Output Type
Texas Instruments DAC81408EVM	12 µs	Board(s)	16 bits	Serial SPI	Voltage	Board	DAC81408	8
Texas Instruments DAC81408RHAR			16 bits	DSP SPI					4.5 V	5.5 V	125 °C	-40 °C	Surface Mount	Internal	1 LSB	0.5 LSB	5.5 V	4.5 V	8 count	40-VFQFN Exposed Pad	R-2R	6 mm	40-VQFN	6 mm	Yes	12 µs	Voltage - Buffered
Texas Instruments DAC81408RHAT			16 bits	DSP SPI					4.5 V	5.5 V	125 °C	-40 °C	Surface Mount	Internal	1 LSB	0.5 LSB	5.5 V	4.5 V	8 count	40-VFQFN Exposed Pad	R-2R	6 mm	40-VQFN	6 mm	Yes	12 µs	Voltage - Buffered
