ADC12DJ4000RF Series

Catalog

RF-SAMPLING 12-BIT ADC WITH 4-GSPS DUAL CHANNEL OR 8-GSPS SINGLE CHANNEL

Part	Package / Case	Package Length	Package Name	Package Width	Ratio - ADC	Ratio - S/H	Architecture	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Operating Temperature (Min)	Operating Temperature (Max)	Voltage - Supply, Analog (Range 2 Min)	Voltage - Supply, Analog (Range 2 Max)	Voltage - Supply, Analog (Range 1 Max)	Voltage - Supply, Analog (Range 1 Min)	Mounting Type	Input Type	Sampling Rate (Per Second)	Reference Type	Configuration	Number of Bits	Number of A/D Converters	Number of Inputs	Data Interface
Texas Instruments ADC12DJ4000RFAAV	144-FBGA FCBGA	10 mm	144-FCBGA	10 mm	2	2	SAR	1.05 V	1.15 V	-40 °C	85 °C	1.8 V	2 V	1.15 V	1.05 V	Surface Mount	Differential	8 GHz	External	ADC	12 bits	2 count	8	JESD204B/C
Texas Instruments ADC12DJ4000RFZEG	144-BGA FCBGA	10 mm	144-FCBGA	10 mm	2	2	SAR	1.05 V	1.15 V	-40 °C	85 °C	1.8 V	2 V	1.15 V	1.05 V	Surface Mount	Differential		External	ADC	12 bits	2 count	8	JESD204B/C
Texas Instruments ADC12DJ4000RFAAVT	144-FBGA FCBGA	10 mm	144-FCBGA	10 mm	2	0	Pipelined SAR	1.05 V	1.15 V	-40 °C	85 °C	1.8 V	2 V	1.15 V	1.05 V	Surface Mount	Differential	4 GHz	External	ADC	12 bits	2 count	8	JESD204B/C
Texas Instruments ADC12DJ4000RFZEGT	144-BGA FCBGA	10 mm	144-FCBGA	10 mm	2	0	Pipelined SAR	1.05 V	1.15 V	-40 °C	85 °C	1.8 V	2 V	1.15 V	1.05 V	Surface Mount	Differential	4 GHz	External	ADC	12 bits	2 count	8	JESD204B/C
